Blow your bottle, Shape your dream

|
| Place of Origin: | Jiangsu, China |
| Brand Name: | eceng |
| Certification: | CE/ISO |
| Model Number: | KB1 |
| Minimum Order Quantity: | 1set |
|---|---|
| Price: | $38,000.00/Sets 1-1 Sets |
| Packaging Details: | packed by wooden pallet or as customer request of 3 gallon 5 gallon water pet bottle blow molding machine |
| Delivery Time: | 30days |
| Payment Terms: | L/C, T/T, Western Union |
| Supply Ability: | 15 Set/Sets per Month |
| Plastic Processed: | PET | Condition: | New |
|---|---|---|---|
| Blow Moulding Type: | Stretch Blow Moulding | Year: | 2019 |
| Voltage: | 220V Or As Customer Request | Dimension(L*W*H): | 6.5*1.8*1.9 |
| Hollow Part Volume: | 20liter | Power (kW): | 49 |
| Weight (KG): | 6000 | Automation: | Automatic |
| Warranty: | 1 Year | Key Selling Points: | Energy Saving |
| Applicable Industries: | Food & Beverage Factory | Automatic: | Yes |
| Style: | Plastic Mineral Water Bottle Blowing Machine | Step: | 2 |
| Heating Method: | Electric Cycle Heating | Service: | Full Technical Training |
| Bottle Volume: | MAX 20Liter | Light Tube: | 32 Pieces |
| Weight: | 6tons | Port: | Shanghai/Ningbo |
| High Light: | KB1 5 Gallon Bottle Blowing Machine,automatic pet bottle blowing machine 12000 kcal/hr,KB1 5 Gallon automatic pet bottle blowing machine |
||
|
Item
|
|
YCQ-20L-1
|
|
|
Bottle type specification
|
Cavity
|
1
|
|
|
|
Theory output
|
350
|
|
|
|
Max.volume
|
20L
|
|
|
|
Bottle mouth maximum overall diameter
|
150mm
|
|
|
|
Bottle biggest diameter
|
350mm
|
|
|
|
Bottle maximum height
|
550mm
|
|
|
Power specifications
|
Light tube quantity
|
48pcs
|
|
|
|
Light tube power
|
1.5KW
|
|
|
|
Maximum heating power
|
72KW
|
|
|
|
All electric machine installation
|
75KW
|
|
|
|
Actual consumption
|
52.5KW
|
|
|
Air pressure specification
|
Work pressure
|
7-9kg/c㎡
|
|
|
|
Low-pressure gas consumption
|
1600L/min
|
|
|
|
Blow bottle pressure
|
25-35kg/c㎡
|
|
|
|
Higher -pressure gas consumption
|
2000-3000Ltr/min
|
|
|
Forzen water specification
|
Work pressure
|
5-6 kg/c㎡
|
|
|
|
Temperature range
|
10℃
|
|
|
|
Consumption
|
12000kcal/hr
|
|
|
|
Forzen water flow
|
88L/min
|
|
|
Machine specification
|
Size of the machine
|
5.2x2.0x2.0
|
|
|
|
Weight of the machine
|
6ton
|
|
