Eceng 18 Cavity PET Bottle Mould S136 Plastic Injection Mold

Eceng 18 Cavity PET Bottle Mould S136 Plastic Injection Mold

  • High Light

    Eceng 18 cavity PET Bottle Mould

    ,

    Eceng 18 cavity Plastic Injection Mold

    ,

    S136 Plastic Injection Mold

  • Shaping Mode
    Plastic Injection Mould
  • Product Material
    Steel
  • Product
    PET Injection Preform Mold
  • Cavities
    18
  • Mould Frame Material
    4Cr13 Stainless Steel
  • Core Material
    S136
  • Cavity Material
    S136
  • Valve Pin Brand
    SKD61 (Japan)
  • Heater Ring Brand
    Hotest(Germany)
  • Port
    Shanghai
  • Place of Origin
    Jiangsu, China
  • Brand Name
    Eceng
  • Certification
    CE SGS ISO
  • Minimum Order Quantity
    1set
  • Price
    $600.00 - $8,200.00/Sets
  • Packaging Details
    standard export wooden case or according to your requirements
  • Delivery Time
    30days
  • Payment Terms
    L/C, T/T, Western Union
  • Supply Ability
    50000 Set/Sets per Year

Eceng 18 Cavity PET Bottle Mould S136 Plastic Injection Mold

Eceng 18 cavity Factory price hot runner gift pack bottle preform mould multi plastic injection Factory price
Eceng 18 Cavity PET Bottle Mould S136 Plastic Injection Mold 0
Eceng 18 Cavity PET Bottle Mould S136 Plastic Injection Mold 2
Eceng 18 Cavity PET Bottle Mould S136 Plastic Injection Mold 4
Packing & Delivery
Eceng 18 Cavity PET Bottle Mould S136 Plastic Injection Mold 6
Eceng 18 Cavity PET Bottle Mould S136 Plastic Injection Mold 8
Eceng 18 Cavity PET Bottle Mould S136 Plastic Injection Mold 10
preform injection mould material
S136
Precision machining
CNC, milling machine, drilling machine, numerical lathe, all types of lathe

Standard
Self made or LKM
Surface finish process
polishing, sand blasting, heat treatment, painting, powder coating, anodizing, electroplating, mirror polishing .

Runner
Hot runner
Shaping mould
injection mould

Specification drawings
Pro/E, Auto CAD, Solidwork, CAXA UG, CAD/CAM/CAE.
Service
OEM service available, good after-sales service .

Specification
Eceng High efficiency good performance custom pet tablet bottle mold injection vertical molding preform
instructions 1: The number of preform cavity from 1 to 96. 2: The bottle preform is designed by computer simulation tensile test to improve the finished product rate of the blown bottle. 3: Adopt the world advanced two-level double-taper positioning technology, each cavity is self-locked independently, to ensure the concentricity of the mold. 4: Mold injection cavity and injection core are made of high quality preheating special die steel from the original Factory in Sweden. 5: Thread mouth according to international standard manufacturing, the material selection of imported nitriding, high hardness, long service life. 6: Advanced design of hot runner, uniform heating temperature, improve the quality of plastic products. 7: no shear gate, reduce the labor intensity of workers. 8: Mold life is guaranteed to be more than 3 million mold times.
Company Profile
Eceng 18 Cavity PET Bottle Mould S136 Plastic Injection Mold 12
Eceng 18 Cavity PET Bottle Mould S136 Plastic Injection Mold 14
Our company specializes in manufacturing plastic machinery and moulds. We are mainly engaged in making automatic PET blow mould machine, semi-automatic PET blow machine, PE/PP/PVE/HDPE extruding blowing machine, injection machine and all kinds of moulds. We have been committed to the design of plastic bottle making machine, especially the fully-automatic PET blow mould machine, from 300ml- 20L. Our machine complying with CE certification has good quality with praise by our customers. Our standard spares are free. We insist on quality first. What's more, we design kinds of plastic moulds for domestic and foreign customers. With a professional design team, we use advanced CAD / CAM / CAE system. We have gained a well-known reputation from our customers.
FAQ
1. who are we?
We are based in Jiangsu, China, start from 2010,sell to Southeast Asia(30.00%),Africa(20.00%),Domestic Market(20.00%),Mid East(15.00%),South America(10.00%),North America(5.00%). There are total about 11-50 people in our office.

2. how can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;

3.what can you buy from us?
Fully Auto Bottle Blowing Machine

4. why should you buy from us not from other suppliers?
We have been committed to the design of plastic bottle making machine, especially the fully-automatic PET blow mould machine, from 300ml- 20L. Our machine complying with CE certification has good quality with praise by our customers. Our standard spares ar

5. what services can we provide?
Accepted Delivery Terms: FOB,CIF,EXW;
Accepted Payment Currency:USD,EUR,CNY;
Accepted Payment Type: T/T,L/C,Western Union;
Language Spoken:English,Chinese
Semi-Automatic PET Bottle Blowing Machine Bottle Making Machine Bottle Moulding Machine PET Bottle Making Machine is suitable for producing PET plastic containers and bottles in all shapes.
