Eceng PET 6 Cavity Automatic Blow Molding Machine Black And White

Eceng PET 6 Cavity Automatic Blow Molding Machine Black And White

Eceng PET 6 Cavity Automatic Blow Molding Machine Black And White
Eceng PET 6 Cavity Automatic Blow Molding Machine Black And White
Eceng PET 6 Cavity Automatic Blow Molding Machine Black And White
Product Details:
Place of Origin: Jiangsu, China
Brand Name: Eceng
Certification: CE ISO
Model Number: K6
Payment & Shipping Terms:
Minimum Order Quantity: 1set
Price: $35,900.00/Sets 1-1 Sets
Packaging Details: standard export wooden case or according to your requirements
Delivery Time: 60days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 500 Set/Sets per Year
Contact Now
Detailed Product Description
Plastic Processed: PET Voltage: 380V,50HZ
Dimension(L*W*H): 5.5*1.8*1.9m Hollow Part Volume: 2L
High Pressure Valve Brand: SMC Rotary Cylinder Brand: SMC
PLC Brand: DELTA Weight (KG): 6100 KG
Automation: Automatic Warranty: 1 Year
Key Selling Points: Automatic Output: 10000
Weight: 6.1tons Power(W): 50KW
Port: Shanghai
High Light:

Eceng PET Automatic Blow Molding Machine

,

6 cavity blowing machine output 10000

,

Eceng PET 6 cavity blowing machine

Plastic making automatic drink bottle maker 6 cavity

Eceg machinery located in zhangjiagangcity, very close to shanghai with beautiful scenery and convenient transportation. Our compant specializes in the production of PET automatic and semi-automatic blowing machines, preform moulds and bottle moulds. It consists of many professional engineers with rich experience in the PET industry and high-quality staff. The main products include: PET automatic and semi-automatic blowing machines, all kinds of moulds for carbonated beverage bottles, juice bottles, alcohol drinks bottles, and cosmetic containers, edible oil bottles, etc. Over the past several years, Eceng has always been devoting its utmost efforts to improving the technology, researching the market and developing new products to suit for all customer needs.



Eceng PET 6 Cavity Automatic Blow Molding Machine Black And White 0







There are two photoelectric sensors to control preform loading motor and preform-separating cylinder that will warn the operator to add preform into hopper when lacks preform instead of stopping the machine



Servo motor control the mold claim, more faster and stable, reduce the noise and improve the effciency

With install hole for mold, when customer change mold, time will be within 30minutes



Auto dropper for finsihed bottle, suitable for different color preform, and suqare or round shape both ok, different neck size just change holder, gripper



Model K6

Bottle type specification



Cavity 6
Max.volume 200ml-2000ml
Bottle mouth maximum overall diameter 25-29mm NECK
Bottle biggest diameter 100mm
Bottle maximum height 330mm

Capacity specification



Theory output 12000-14000BPH
Bottle type volume 600ML
Bottle type weight 13.5g
Bottle type Round
Power specification Light tube quantity 32pcs
Light tube power 1.25KW
Maximum heating power 40KW
All electric machine installation 49KW
Actual consumption 30%--60%

Air pressure specification



Work pressure 5-6kg/cm2
Blow bottle pressure 25-45kg/cm2
Higher -pressure gas consumption 8000Ltr/min
Forzen water specification Work pressure 5-6 kg/cm2
Temperature range 10℃
Consumption 8000kcal/hr
Forzen water flow 120L/min
Machine specification Machine size 5.5x1.8x1.9
Machine weight 6.1ton



Eceng PET 6 Cavity Automatic Blow Molding Machine Black And White 1





Standard Installation service
When you finish the Preparation conditions, our fast and professional aftersales service engineer team will go to your factory to install the machine, give you the operating manual, and train your employee until they can operate the machine well.

The sample service
1. We can send you the video of the running machine.
2. You are welcome to come to visit our factory, and see the machine running.



What we can do more

If thre are any damaged spare parts or accessories, we will replace them by DHL express immediately Free of Charge



Well-trained & experienced staff are to answer all your inquiries in English and Chinese



Download software, we can update your program by Internet







1. We focus all our attention in stretch molding machine in past 15 years, all our mind and technogy made eceng blowing machine more strong



2. More machine color and voltage for customer to choose



3. We keep ready machine all the time, when customer place urgent order, we can arrange in time

Eceng PET 6 Cavity Automatic Blow Molding Machine Black And White 2

FAQ

Q:Your company is a trading company or a direct factory?
A:We are a direct factory which locates in Zhangjiagang city.
Q:All of your products are made by yourself or compacted via purchasing the others?
A:We have independent technical team who focus on making machines,all the products are made by our technical team.
Q:What is the ability of your factory?
A:About 80 lines per year.
Q:Do you have any other services about your products?
A:We have a lot of experience on making projects and specifications for our clients,also we have a fixed service system.
Q:How do you make the quotation for clients?
A:The price depends on quality and performance but the clients should be satisfied first.
