2 Liter Plastic Mineral Water Bottle Making Machine 380V 50HZ

2 Liter Plastic Mineral Water Bottle Making Machine 380V 50HZ

  • High Light

    2 liter mineral water bottle making machine

    ,

    mineral water bottle making machine 380V 50HZ

    ,

    plastic bottle blowing machine 380V 50HZ

  • Plastic Processed
    PET
  • Max.Bottle Height(mm)
    330 Mm
  • Neck Diameter(mm)
    28 Mm
  • Max.Bottle Diameter(mm)
    100 Mm
  • Bottle Volume(ml)
    2000 Ml
  • Condition
    New
  • Application
    Bottle
  • Blow Moulding Type
    Stretch Blow Moulding
  • Year
    2019
  • Voltage
    380V,50HZ
  • Dimension(L*W*H)
    5.5*1.8*1.9m
  • Hollow Part Volume
    2L
  • PLC Brand
    DELTA
  • Power (kW)
    49
  • Weight (KG)
    6100 KG
  • Automation
    Automatic
  • Warranty
    1 Year, One Year For Free
  • Key Selling Points
    Automatic
  • Applicable Industries
    Food & Beverage Factory
  • Marketing Type
    Hot Product 2019
  • Machinery Test Report
    Provided
  • Video Outgoing-inspection
    Provided
  • Warranty Of Core Components
    1 Year
  • Automatic
    Yes
  • Color
    Black And White
  • Warranty
    1 Year
  • Output
    10000
  • Size Of The Machine
    5.5*1.8*1.9
  • Weight
    6.1tons
  • Power(W)
    50KW
  • Port
    SHANGHAI
  • Place of Origin
    Jiangsu, China
  • Brand Name
    Eceng
  • Certification
    CE SGS ISO
  • Model Number
    K6
  • Minimum Order Quantity
    1set
  • Price
    $35,000.00/Sets >=1 Sets
  • Packaging Details
    standard export wooden case or according to your requirements

2 Liter Plastic Mineral Water Bottle Making Machine 380V 50HZ

500ml plastic water bottle/juice beverage bottle blowing machine
PET Mold Blower / PET Bottle Blowing Machine / Mineral Water Bottle Making Machine
2 Liter Plastic Mineral Water Bottle Making Machine 380V 50HZ 0
specification
             Model                                                                             K6






Bottle type specification
Cavity
6

Max.volume
2L

Bottle mouth maximum overall diameter
28-30mm

Bottle biggest diameter
100mm

Bottle maximum height
330mm


Capacity specification
Theory output
9000~12000BPH

Bottle type volume
500ML

Bottle type weight
17g

Bottle type
Round



Power specification
Light tube quantity
32pcs

Light tube power
1.25KW

Maximum heating power
40KW

All electric machine installation
49KW

Actual consumption
30%--60%


Air pressure specification
Work pressure
5-6kg/cm2

Blow bottle pressure
25-45kg/cm2

Higher -pressure gas consumption
8000Ltr/min


Air pressure specification
Work pressure
5-6 kg/cm2

Temperature range
10℃

Consumption
8000kcal/hr

Forzen water flow
120L/min

Machine specification
Machine size
5.5x1.8x1.9

Machine weight
6.1ton
2 Liter Plastic Mineral Water Bottle Making Machine 380V 50HZ 2
K series is a stable two-step blow-down stretch automatic blowing machine.It can be used from 4 cavity to 12 cavity with a speed of 1500 bottles per hour (750 ml plastic bottles),max volume 2L plastic bottle,suitable for blowing any kind of carbonated beverage bottle,sparkling beverage bottle,pure water bottle, mineral water bottle,fruit juice beverage bottle,cosmetic bottles,large diameter bottles, high temperature resistance bottles and other packaging bottles.
Detailed Images
2 Liter Plastic Mineral Water Bottle Making Machine 380V 50HZ 4
2 Liter Plastic Mineral Water Bottle Making Machine 380V 50HZ 6
K linear bottle blowing machine adopts advanced microcomputer PLC control system, stable performance,manual type and fully automatic type. J series linear bottle blowing machine features: 1.stable and accurate running at high speed,adopt more stable and advanced microcomputer PLC control system. 2. production process is fully automated, with the advantages of low investment, high efficiency, easy operation, simple maintenance and safety. 3. suitable for flexible production of quantity and various bottle shape,wide range of applications,meet customer needs. 4. manual and automatic methods of operation, human-machine interface control, simple operation. 5. servo transmission system, high positioning accuracy, fast speed stability and good reliability. 6. less than 0.2% scrap rate for finished bottle .
Company Introduction
2 Liter Plastic Mineral Water Bottle Making Machine 380V 50HZ 8
Packing&Shipping
2 Liter Plastic Mineral Water Bottle Making Machine 380V 50HZ 10
After Sales Service
1. Installation, debug We will arrange seasoned technician for debug and test production at the same time make the equipment reach the rated producing capacity of the line. 2. Training Our company offer technology training to customer. The content of training is structure and maintenance of equipment, control and operation of equipment. After training, the technician of buyer could master the operation and maintenance, could adjust the process and treat different failures. 3. Quality guarantee We promise that our goods quality, specification and function all meet the demand of contract. One year warranty,during warranty period,All parts and components except those damaged by non-human factors are guaranteed free of charge (vulnerable parts are not included). In addition, the seller provides free spare parts and accessories for shipment with the machine. During warranty period ,the equipment is damaged due to incorrect operation bythe buyer,we provide maintenance solutions,the buyer will cover the loss and cost.during warranty period we provide technical service,which is usually solved by telephone,etc.if not,provide door-to-door service.
2 Liter Plastic Mineral Water Bottle Making Machine 380V 50HZ 12
2 Liter Plastic Mineral Water Bottle Making Machine 380V 50HZ 14
2 Liter Plastic Mineral Water Bottle Making Machine 380V 50HZ 16
FAQ
Q:Your company is a trading company or a direct factory?
A:We are a direct factory which locates in Zhangjiagang city.
Q:All of your products are made by yourself or compacted via purchasing the others?
A:We have independent technical team who focus on making machines,all the products are made by our technical team.
Q:What is the ability of your factory?
A:About 80 lines per year.
Q:Do you have any other services about your products?
A:We have a lot of experience on making projects and specifications for our clients,also we have a fixed service system.
Q:How do you make the quotation for clients?
A:The price depends on quality and performance but the clients should be satisfied first.
