Eceng Straight PET Stretch Blowing Machine DELTA PLC Control

Eceng Straight PET Stretch Blowing Machine DELTA PLC Control

  • High Light

    Eceng straight PET Stretch Blowing Machine

    ,

    pet blow moulding machine DELTA PLC

    ,

    Eceng straight pet blow moulding machine

  • Plastic Processed
    PET
  • Max.Bottle Height(mm)
    330 Mm
  • Neck Diameter(mm)
    28 Mm
  • Max.Bottle Diameter(mm)
    180 Mm
  • Bottle Volume(ml)
    2000 Ml
  • Condition
    New
  • Application
    Bottle
  • Blow Moulding Type
    Stretch Blow Moulding
  • Year
    2019
  • Voltage
    380V,50HZ
  • Dimension(L*W*H)
    4.5*1.6*1.9m
  • Hollow Part Volume
    2L
  • High Pressure Valve Brand
    SMC
  • Rotary Cylinder Brand
    SMC
  • PLC Brand
    DELTA
  • Power (kW)
    49
  • Weight (KG)
    6100 KG
  • Automation
    Automatic
  • Warranty
    1 Year
  • Key Selling Points
    Automatic
  • Applicable Industries
    Manufacturing Plant
  • Marketing Type
    Hot Product 2019
  • Machinery Test Report
    Provided
  • Video Outgoing-inspection
    Provided
  • Warranty Of Core Components
    1 Year
  • Color
    Yellow
  • Output
    4500-5000
  • Size Of The Machine
    4.5*1.6*1.9
  • Weight
    3.5tons
  • Power(W)
    43KW
  • Port
    Shanghai
  • Place of Origin
    Jiangsu, China
  • Brand Name
    Eceng
  • Certification
    CE ISO
  • Model Number
    YCQ-2L-4
  • Minimum Order Quantity
    1set
  • Price
    $25,000.00 - $45,000.00/Sets
  • Packaging Details
    standard export wooden case or according to your requirements
  • Delivery Time
    45days
  • Payment Terms
    L/C, T/T, Western Union
  • Supply Ability
    500 Set/Sets per Year

Eceng Straight PET Stretch Blowing Machine DELTA PLC Control

Eceng tablet bottles fully automatic straight PET bottle blowing machine
Eceng Straight PET Stretch Blowing Machine DELTA PLC Control 0
specification
             Model                                                                    K6






Bottle type specification
Cavity
6

Max.volume
2L

Bottle mouth maximum overall diameter
28-30mm

Bottle biggest diameter
100mm

Bottle maximum height
330mm


Capacity specification
Theory output
9000~12000BPH

Bottle type volume
500ML

Bottle type weight
17g

Bottle type
Round



Power specification
Light tube quantity
32pcs

Light tube power
1.25KW

Maximum heating power
40KW

All electric machine installation
49KW

Actual consumption
30%--60%


Air pressure specification
Work pressure
5-6kg/cm2

Blow bottle pressure
25-45kg/cm2

Higher -pressure gas consumption
8000Ltr/min


Air pressure specification
Work pressure
5-6 kg/cm2

Temperature range
10℃

Consumption
8000kcal/hr

Forzen water flow
120L/min

Machine specification
Machine size
5.5x1.8x1.9

Machine weight
6.1ton
Eceng Straight PET Stretch Blowing Machine DELTA PLC Control 2
Eceng Straight PET Stretch Blowing Machine DELTA PLC Control 4
Eceng tablet bottles fully automatic straight PET bottle blowing machine
YCQ series fully automatic machine is developed by advanced bottle blowing technology, it has a lot of advantages as below. 1.  Reasonable price & Good after service 2.  experienced skilled workers and professional engineers 3.  Good quality ,excellent service ,long life mould. 4.  on time delivery time 5.  Send project schedule report and pictures to buyer to show the progress of the machining. 6.  Our international sales team work 24 hours per day to serve you

blowing mould
Eceng Straight PET Stretch Blowing Machine DELTA PLC Control 6
Eceng Straight PET Stretch Blowing Machine DELTA PLC Control 8
Eceng Straight PET Stretch Blowing Machine DELTA PLC Control 10
Eceng Straight PET Stretch Blowing Machine DELTA PLC Control 12
Eceng Straight PET Stretch Blowing Machine DELTA PLC Control 14
Eceng Straight PET Stretch Blowing Machine DELTA PLC Control 16
Zhangjiagang Eceng Machinery Co., Ltd is founded in 2007,located in Zhangjiagang city,only 120km away from Shanghai.We are professional manufacturer of PET bottle blowing machines and plastic molds. We manufacture fully-automatic PET bottle blowing machine, injection mold,blowing mold etc.,suitable for 5ml-50L plastic bottles,water bottles,carbonated beverage bottles,oil bottles,cosmetics bottles.We can equip machine from 1-12 cavity,output from hundreds bottles to 20,000 bottles/hour,also provide full set of production system from preform production,bottle blowing,filling to final packaging. Our products has covered all over China and exported to more than 100 countries,including Southest Asia,Middle East,South America,Africa etc.We’d like to provide high quality solution to clients with our enthusiasm and rich experience.We sincerely hope to establish business relationship with friends all over the world.
Packing&Shipping

Eceng Straight PET Stretch Blowing Machine DELTA PLC Control 18

Eceng Straight PET Stretch Blowing Machine DELTA PLC Control 20
Normally the inner package, we will packed by the stretch film. Outer package we will use the export woodencase. Mostly we deliver the goods by sea as the freight is most reasonable in this way.
FAQ
Q:Your company is a trading company or a direct factory?
A:We are a direct factory which locates in Zhangjiagang city.
Q:All of your products are made by yourself or compacted via purchasing the others?
A:We have independent technical team who focus on making machines,all the products are made by our technical team.
Q:What is the ability of your factory?
A:About 80 lines per year.
Q:Do you have any other services about your products?
A:We have a lot of experience on making projects and specifications for our clients,also we have a fixed service system.
Q:How do you make the quotation for clients?
A:The price depends on quality and performance but the clients should be satisfied first.
