Plastic Beverage Bottle PET Stretch Blowing Machine 4000kg 6000BPH

Plastic Beverage Bottle PET Stretch Blowing Machine 4000kg 6000BPH

Plastic Beverage Bottle PET Stretch Blowing Machine 4000kg 6000BPH
Plastic Beverage Bottle PET Stretch Blowing Machine 4000kg 6000BPH
Plastic Beverage Bottle PET Stretch Blowing Machine 4000kg 6000BPH
Product Details:
Place of Origin: China
Brand Name: Eceng
Certification: CE ISO
Model Number: Q6000
Payment & Shipping Terms:
Minimum Order Quantity: 1set
Price: $35,000.00/Sets 1-1 Sets
Packaging Details: PET bottle making machine is in wooden case packing or as customers request.
Delivery Time: 45days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 6 Set/Sets per Month
Contact Now
Detailed Product Description
Blow Moulding Type: Stretch Blow Moulding Voltage: Customer Request
Automation: Automatic Applicable Industries: Food & Beverage Factory
Automatic: Yes Bottle Volume: 150ml-2000ml
Cavity: 6 Material: Pet Preform
Replacement Assembly Parts: Provide For Free Model Type: PET Bottle Making Machine
High Light:

beverage bottle PET Stretch Blowing Machine 4000kg

,

plastic bottle blowing machine 6000BPH

,

plastic bottle blowing machine 4000kg

Plastic Beverage Bottle PET Stretch Blowing Machine 4000kg 6000BPH

Plastic Beverage Bottle PET Stretch Blowing Machine 4000kg 6000BPH 0

Plastic Beverage Bottle PET Stretch Blowing Machine 4000kg 6000BPH 1



Model Q6000

Bottle type specification



Cavity 4
Max.volume 2L
Bottle mouth maximum overall diameter 28-38mm
Bottle biggest diameter 105mm
Bottle maximum height 330mm
Production specification Theoretical output 6000BPH
Bottle type capacity 500ML
Bottle type weight 17g
Bottle type circular
Power specification Light tube quantity 32pcs
Light tube power 1.5KW
Maximum heating power 48KW
All electric machine installation 52KW
Actual consumption 40%--70%

Air pressure specification



Work pressure 7-9kg/cm2
Low-pressure gas consumption 1000L/min
Blow bottle pressure 25-35kg/cm2
Higher -pressure gas consumption 3000Ltr/min

Air pressure specification



Work pressure 5-6 kg/cm2
Temperature range 10℃
Consumption 8000kcal/hr
Forzen water flow 138L/min

Machine specification



Machine size 4.2x1.6x1.9
Machine weight 4.5ton
Q series is a stable two-step blow-down stretch automatic blowing machine.It can be used from 2 cavity to 9 cavity with a speed of 1500 bottles per hour (500 ml plastic bottles),max volume 2L plastic bottle,suitable for blowing any kind of carbonated beverage bottle,sparkling beverage bottle,pure water bottle, mineral water bottle,fruit juice beverage bottle,cosmetic bottles,large diameter bottles, high temperature resistance bottles and other packaging bottles.

Q linear bottle blowing machine adopts advanced microcomputer PLC control system, stable performance,manual type and fully automatic type. Q series linear bottle blowing machine features:

1.stable and accurate running at high speed,adopt more stable and advanced microcomputer PLC control system.

2. production process is fully automated, with the advantages of low investment, high efficiency, easy operation, simple maintenance and safety.

3. suitable for flexible production of quantity and various bottle shape,wide range of applications,meet customer needs.

4. manual and automatic methods of operation, human-machine interface control, simple operation.

5. servo transmission system, high positioning accuracy, fast speed stability and good reliability.

6. less than 0.2% scrap rate for finished bottle .

Fully Automatic Water Beverages Bottle Blowing Machine K8 8 Cavitys 16

Plastic Beverage Bottle PET Stretch Blowing Machine 4000kg 6000BPH 3

Plastic Beverage Bottle PET Stretch Blowing Machine 4000kg 6000BPH 4

Zhangjiagang Eceng Machinery Co., Ltd is founded in 2007,We manufacture fully-automatic PET bottle blowing machine, injection mold,blowing mold etc.,suitable for 5ml-50L plastic bottles,water bottles,carbonated beverage bottles,oil bottles,cosmetics bottles.We can equip machine from 1-12 cavity,output from hundreds bottles to 36,000 bottles/hour,also provide full set of production system from preform production,bottle blowing,filling to final packaging.
So far Eceng machinery have provided more than 2050 sets machines for more than 170 countries in the world.Our equipments are highly estimated by the clients, and are well known at home and abroad.We sincerely hope to establish business relationship with friends all over the world.

Plastic Beverage Bottle PET Stretch Blowing Machine 4000kg 6000BPH 5
Plastic Beverage Bottle PET Stretch Blowing Machine 4000kg 6000BPH 6



our advantage:1. Resonable price;2. Good after service;3. experienced skilled workers and professional engineers;4. Good quality ,excellent service ,long life mould;5. on time delivery time;6.our engineers can be online for 24 hours to serve you.



Plastic Beverage Bottle PET Stretch Blowing Machine 4000kg 6000BPH 7

Normally the inner package, we will packed by the stretch film. Outer package we will use the export woodencase. Mostly we deliver the goods by sea as the freight is most reasonable in this way.

Plastic Beverage Bottle PET Stretch Blowing Machine 4000kg 6000BPH 8

After Sales Service
1. Installation, debug
We will arrange seasoned technician for debug and test production at the same time make the equipment reach the rated producing capacity of the line.
2. Training
Our company offer technology training to customer. The content of training is structure and maintenance of equipment, control and operation of equipment. After training, the technician of buyer could master the operation and maintenance, could adjust the process and treat different failures.
3.the sample service
1'We can send you the video of the running machine.
2'You are welcome to come to visit our factory,and see the machine running.
3.We can design the machines according your requirements,at the same time we will give you our professional suggestion,as you know,we have been in this industry for 17 years.
4.We provide one year warranty
5.well-trained & experienced staff are to answer all your inquiries in English and Chinese
6.12 Months guarantee and life-long technical support.
7.Your business relationship with us will be confidential to any third party.
8. Good after-sale service offered, please get back to us if you got any questions.

Plastic Beverage Bottle PET Stretch Blowing Machine 4000kg 6000BPH 9

FAQ

Q:Your company is a trading company or a direct factory?

A:We are a direct factory which locates in Zhangjiagang city.

Q:All of your products are made by yourself or compacted via purchasing the others?

A:We have independent technical team who focus on making machines,all the products are made by our technical team.

Q:What is the ability of your factory?

A:About 80 lines per year.

Q:Do you have any other services about your products?

A:We have a lot of experience on making projects and specifications for our clients,also we have a fixed service system.

Q:How do you make the quotation for clients?

A:The price depends on quality and performance but the clients should be satisfied first.
