1300bpn PET Jar Blow Molding Machine Plastic Bottle Manufacturing 2 Cavity

1300bpn PET Jar Blow Molding Machine Plastic Bottle Manufacturing 2 Cavity

  • High Light

    1300bpn PET Jar Blow Molding Machine

    ,

    1300bpn plastic bottle manufacturing machine

    ,

    plastic bottle manufacturing machine 2 Cavity

  • Plastic Processed
    PET
  • Max.Bottle Height(mm)
    400 Mm
  • Neck Diameter(mm)
    150 Mm
  • Max.Bottle Diameter(mm)
    180 Mm
  • Bottle Volume(ml)
    5000 Ml
  • Condition
    New
  • Application
    Bottle, Plastic Bottle
  • Blow Moulding Type
    Stretch Blow Moulding
  • Year
    2019
  • Voltage
    3phase 380V/220V
  • Dimension(L*W*H)
    4.7x1.6x1.9(m)
  • Hollow Part Volume
    5L
  • Power (kW)
    35.7
  • Weight (KG)
    3000 KG
  • Automation
    Automatic
  • Warranty
    1 Year
  • Key Selling Points
    Automatic
  • Applicable Industries
    Food & Beverage Shops
  • Machinery Test Report
    Provided
  • Video Outgoing-inspection
    Provided
  • Warranty Of Core Components
    1 Year
  • Automatic
    Yes
  • Color
    Orange
  • Cavity
    2
  • Output
    1200-1300BPH
  • Factory Location
    Zhangjiagang,nearby Shanghai
  • Port
    Shanghai
  • Place of Origin
    Jiangsu, China
  • Brand Name
    Eceng
  • Certification
    CE&ISO
  • Model Number
    J2
  • Minimum Order Quantity
    1set
  • Price
    $40,000.00/Sets 1-1 Sets
  • Packaging Details
    Wooden package
  • Delivery Time
    45days
  • Payment Terms
    L/C, T/T, Western Union
  • Supply Ability
    10 Set/Sets per Month

1300bpn PET Jar Blow Molding Machine Plastic Bottle Manufacturing 2 Cavity

Eceng Pet Bottle Molding Machine Suppliers High Output Manufacturer PET Plastic Wide mouth bottles Making Machine

bottle making machine / bottle stretch blowing machine J2

Item J2
Bottle type specification Cavity 2
Theory output 1200-1300
Max.volume 5L
Bottle mouth maximum overall DIdiameter 150mm
Bottle biggest diameter 180mm
Bottle maximum height 400mm
Power specifications Light tube quantity 32pcs
Light tube power 1.5KW
Maximum heating power 48KW
All electric machine installation 51KW
Actual consumption 35.7KW
Air pressure specification Work pressure 7-9kg/cm2
Low-pressure gas consumption 1600L/min
Blow bottle pressure 25-35kg/cm2
Higher -pressure gas consumption 3400Ltr/min
Forzen water specification Work pressure 5-6 kg/cm2
Temperature range 10℃
Consumption 6000kcal/hr
Forzen water flow 50L/min
Machine specification Size of the machine 4.7x1.6x1.9
Weight of the machine 3ton



1300bpn PET Jar Blow Molding Machine Plastic Bottle Manufacturing 2 Cavity 0

 1300bpn PET Jar Blow Molding Machine Plastic Bottle Manufacturing 2 Cavity 2

 1300bpn PET Jar Blow Molding Machine Plastic Bottle Manufacturing 2 Cavity 4



















company introduction



Our company, Zhangjiagang Eceng Machinery Co., Ltd. we are a special manufacturer of PET bottle blowing machine,blow molding machine and mould, We have been engaged in moulds for years, and have gained a well-known reputation from our customers who spread all over the world.







1300bpn PET Jar Blow Molding Machine Plastic Bottle Manufacturing 2 Cavity 6



   We Warmly Welcome Customers All Over The World To Our Company!
