5L Snack Bottle Pet Stretch Blow Moulding Machine 2 Cavity Semi Automatic For 2L

5L Snack Bottle Pet Stretch Blow Moulding Machine 2 Cavity Semi Automatic For 2L

  • 5L Snack Bottle Pet Stretch Blow Moulding Machine 2 Cavity Semi Automatic For 2L
  • 5L Snack Bottle Pet Stretch Blow Moulding Machine 2 Cavity Semi Automatic For 2L
5L Snack Bottle Pet Stretch Blow Moulding Machine 2 Cavity Semi Automatic For 2L
Product Details:
Place of Origin: Jiangsu, China
Brand Name: Eceng
Certification: CE,ISO
Model Number: YC-5L-2
Payment & Shipping Terms:
Minimum Order Quantity: 1 SET
Price: $6,000.00 - $8,000.00/Sets
Packaging Details: Wooden package
Delivery Time: 10sets per month
Payment Terms: L/C, T/T, Western Union
Supply Ability: 20 Set/Sets per Month
Contact Now
Detailed Product Description
Plastic Processed: PET Bottle Volume(ml): 5000 Ml
Condition: New Application: Bottle
Voltage: 380V, 50HZ, 3PHASE Dimension(L*W*H): 1.7*0.85*2.1(m)
Hollow Part Volume: 5L Weight (KG): 800 KG
Automation: Semi-automatic Key Selling Points: Easy To Operate
Port: Shanghai
High Light:

Bottle Pet Stretch Blow Moulding Machine

,

5L Snack Stretch Blow Moulding Machine

,

Stretch Blow Moulding Machine Semi Automatic

Eceng 5L snack bottle 2 cavity high quality semi automatic pet stretch blow moulding machine manufacturer for 2L upto 5L pet bottles

 5L Snack Bottle Pet Stretch Blow Moulding Machine 2 Cavity Semi Automatic For 2L 0

5L Snack Bottle Pet Stretch Blow Moulding Machine 2 Cavity Semi Automatic For 2L 2

Semi automatic 5L liter pet water bottle  bottol makeing making blowing machine

YC series Plastic making Top quality useful semi automatic pet blowing machinery is controlled by microcomputer. The plastic blowing machine can control the technical parameters more accurately.With the upper and lower system,emergency stop system,independent counter device,count the output accurately.With infrared lamp heating device,penetrating power, preform rotation heating, heating evenly and quickly.YC series semi-automatic plastic bottle blowing machine is suitable for blowing plastic PET bottles such as carbonated beverage bottles,mineral water bottles, cosmetic bottles and hot filling bottles etc.

5L Snack Bottle Pet Stretch Blow Moulding Machine 2 Cavity Semi Automatic For 2L 4





Main machine  (blower + oven)

Item

YC-5L-2

Product Spec

Max. product volume(L/cav)

5

Max. preform neck size(mm)

130

Max. product diameter(mm)

200

Max. product height (mm)

400

Cavities

2

Blow molding part

Die force (KN)

150

Die stroke (mm)

300

Max. mould size(mm)

390*530

Mould thickness

Adjustable

Mould spacing(mm)

Adjustable

Max. pulling stroke(mm)

500

Operation pressure(Mpa)

0.8-1.0

Operation air pressure consumption

(1tr/min)

350

Blow pressure(Mpa)

1.2-2.8

Blow air pressure consumption (1tr/min)

360

Output(pcs/h)

700(5L bottle)

Machine size(LxWxH)(m)

1.7*0.85*2.1

Machine weight(KG)

800

Oven

Temperature grade(rate)

8

Heating time(S)

90-200

Voltage(V)

220 or as your request

Frequency(HZ)

50/60

Total power(KW)

16

Oven Size (LxWxH)

1.45*0.65*1.15

Oven weight (KG)

330

5L Snack Bottle Pet Stretch Blow Moulding Machine 2 Cavity Semi Automatic For 2L 6

5L Snack Bottle Pet Stretch Blow Moulding Machine 2 Cavity Semi Automatic For 2L 8

YC series semi-automatic bottle blowing machine is controlled by microcomputer,control the technical parameters more accurately.PET bottle blowing machine is simple and safe to operate.It only requires one person and does not require special training.YC series PET blow molding machine is suitable for blow molding of plastic packaging bottles such as carbonated beverage bottles, mineral water bottles, hot filling bottles and cosmetic bottles. It is suitable for the production of small beverage companies and daily chemical product companies.

 5L Snack Bottle Pet Stretch Blow Moulding Machine 2 Cavity Semi Automatic For 2L 10

Adopt infrared lamp heating, strong penetration, preform rotation heating, track revolution, heating evenly, fast and reliable; heating lamp,reflector width and height can be adjusted to suit preform heating of different structure,with automatic temperature-removal device to ensure the constant temperature of oven.

 5L Snack Bottle Pet Stretch Blow Moulding Machine 2 Cavity Semi Automatic For 2L 12

Specially designed high rigidity composite mold structure, wide applicability, suitable for various types of mold thickness, easy to adjust and save energy, less air demand, precision polished spindle, equipped with photoelectric sensor, low noise,rapid response, long working hours , stable performance,ensure stable operation.

 5L Snack Bottle Pet Stretch Blow Moulding Machine 2 Cavity Semi Automatic For 2L 14

YC linear bottle blowing machine adopts advanced microcomputer PLC control system, stable performance,manual type and fully automatic type.







Q:Your company is a trading company or a direct factory?

A:We are a direct factory which locates in Zhangjiagang city.

Q:All of your products are made by yourself or compacted via purchasing the others?

A:We have independent technical team who focus on making machines,all the products are made by our technical team.

Q:What is the ability of your factory?

A:About 80 lines per year.

Q:Do you have any other services about your products?

A:We have a lot of experience on making projects and specifications for our clients,also we have a fixed service system.

Q:How do you make the quotation for clients?

A:The price depends on quality and performance but the clients should be satisfied first.
