Home ProductsSemi Auto PET Bottle Blowing Machine

Semi Auto Pet Oil Bottle Blowing Mould Machine 4 Cavities 2800BPH

Semi Auto Pet Oil Bottle Blowing Mould Machine 4 Cavities 2800BPH

  • Semi Auto Pet Oil Bottle Blowing Mould Machine 4 Cavities 2800BPH
  • Semi Auto Pet Oil Bottle Blowing Mould Machine 4 Cavities 2800BPH
Semi Auto Pet Oil Bottle Blowing Mould Machine 4 Cavities 2800BPH
Product Details:
Place of Origin: Jiangsu, China
Brand Name: Eceng
Certification: CE SGS ISO
Model Number: B4
Payment & Shipping Terms:
Minimum Order Quantity: 1set
Price: $35,800.00/Sets 1-1 Sets
Packaging Details: standard export wooden case or according to your requirements
Delivery Time: 10days
Payment Terms: L/C, T/T, Western Union, L/C
Supply Ability: 500 Set/Sets per Year
Contact Now
Detailed Product Description
Plastic Processed: PET Bottle Volume(ml): 2000 Ml
Voltage: 380V,50HZ Warranty: 1 Year
Key Selling Points: Easy To Operate Warranty Of Core Components: 1 Year
Color: Blue/Orange Output: 2600-2800BPH
High Light:

Pet Oil Bottle Blowing Mould Machine

,

4 Cavities Oil Bottle Blowing Machine

,

2800BPH Oil Bottle Blowing Mould Machine

Eceng Semi-automatic pet plastic blowing machine stretch blow moulding machine
Semi Auto Pet Oil Bottle Blowing Mould Machine 4 Cavities 2800BPH 0
specification
             Model                                                                    YC-2L-4






Bottle type specification
Cavity
4

Max.volume
2L

Bottle mouth maximum overall diameter
100mm

Bottle biggest diameter
180mm

Bottle maximum height
300mm


           Blow molding part


Die force (KN)
100

Die stroke (mm)
270

Max. mould size(mm)
390*345

Mould thickness
Adjustable






          Blow molding part
Mould spacing(mm)
Adjustable

Max. pulling stroke(mm)
400

Operation pressure(Mpa)
0.8-1.0

Operation air pressure consumption(1tr/min)
200

Blow pressure(Mpa)
1.2-2.8

Blow air pressure consumption (1tr/min)
300

Output(pcs/h)
2600-2800

Machine size(L×W×H)(m)
1.46×0.58×1.8

Machine weight(KG)
650



Oven
Temperature grade(rate)
8

Heating time(S)
90-200

Voltage(V)
220 or as your request

Frequency(HZ)
50/60

Total power(KW)
16

Oven Size (L×W×H)
1.35×0.55×1.15

Oven weight (KG)
300
Semi Auto Pet Oil Bottle Blowing Mould Machine 4 Cavities 2800BPH 2
Semi Auto Pet Oil Bottle Blowing Mould Machine 4 Cavities 2800BPH 4

YC series Plastic making Top quality useful semi automatic pet blowing machinery is controlled by microcomputer. The plastic blowing machine can control the technical parameters more accurately.With the upper and lower system,emergency stop system,independent counter device,count the output accurately.With infrared lamp heating device,penetrating power, preform rotation heating, heating evenly and quickly.YC series semi-automatic plastic bottle blowing machine is suitable for blowing plastic PET bottles such as carbonated beverage bottles,mineral water bottles, cosmetic bottles and hot filling bottles etc.

Semi Auto Pet Oil Bottle Blowing Mould Machine 4 Cavities 2800BPH 7

YC series semi-automatic bottle blowing machine is controlled by microcomputer,control the technical parameters more accurately.PET bottle blowing machine is simple and safe to operate.It only requires one person and does not require special training.YC series PET blow molding machine is suitable for blow molding of plastic packaging bottles such as carbonated beverage bottles, mineral water bottles, hot filling bottles and cosmetic bottles. It is suitable for the production of small beverage companies and daily chemical product companies.

Adopt infrared lamp heating, strong penetration, preform rotation heating, track revolution, heating evenly, fast and reliable;
heating lamp,reflector width and height can be adjusted to suit preform heating of different structure,with automatic
temperature-removal device to ensure the constant temperature of oven.

Specially designed high rigidity composite mold structure, wide applicability, suitable for various types of mold thickness, easy to adjust and save energy, less air demand, precision polished spindle, equipped with photoelectric sensor, low noise,rapid response, long working hours , stable performance,ensure stable operation.

YC linear bottle blowing machine adopts advanced microcomputer PLC control system, stable performance,manual type and fully automatic type.

blowing mould
Semi Auto Pet Oil Bottle Blowing Mould Machine 4 Cavities 2800BPH 9
Company Introduction
Semi Auto Pet Oil Bottle Blowing Mould Machine 4 Cavities 2800BPH 12
Semi Auto Pet Oil Bottle Blowing Mould Machine 4 Cavities 2800BPH 14
Zhangjiagang Eceng Machinery Co., Ltd is founded in 2007,located in Zhangjiagang city,only 120km away from Shanghai.We are professional manufacturer of PET bottle blowing machines and plastic molds. We manufacture fully-automatic PET bottle blowing machine, injection mold,blowing mold etc.,suitable for 5ml-50L plastic bottles,water bottles,carbonated beverage bottles,oil bottles,cosmetics bottles.We can equip machine from 1-12 cavity,output from hundreds bottles to 20,000 bottles/hour,also provide full set of production system from preform production,bottle blowing,filling to final packaging. Our products has covered all over China and exported to more than 100 countries,including Southest Asia,Middle East,South America,Africa etc.We’d like to provide high quality solution to clients with our enthusiasm and rich experience.We sincerely hope to establish business relationship with friends all over the world.
Packing&Shipping
Semi Auto Pet Oil Bottle Blowing Mould Machine 4 Cavities 2800BPH 16
Normally the inner package, we will packed by the stretch film. Outer package we will use the export woodencase. Mostly we deliver the goods Semi Auto Pet Oil Bottle Blowing Mould Machine 4 Cavities 2800BPH 18
by sea as the freight is most reasonable in this way.
FAQ
Q:Your company is a trading company or a direct factory?
A:We are a direct factory which locates in Zhangjiagang city.
Q:All of your products are made by yourself or compacted via purchasing the others?
A:We have independent technical team who focus on making machines,all the products are made by our technical team.
Q:What is the ability of your factory?
A:About 80 lines per year.
Q:Do you have any other services about your products?
A:We have a lot of experience on making projects and specifications for our clients,also we have a fixed service system.
Q:How do you make the quotation for clients?
A:The price depends on quality and performance but the clients should be satisfied first.
