PET Water Bottle Blowing Equipment Eceng K4 Energy Juice Oil 2000 Ml

PET Water Bottle Blowing Equipment Eceng K4 Energy Juice Oil 2000 Ml

  • PET Water Bottle Blowing Equipment Eceng K4 Energy Juice Oil 2000 Ml
  • PET Water Bottle Blowing Equipment Eceng K4 Energy Juice Oil 2000 Ml
  • PET Water Bottle Blowing Equipment Eceng K4 Energy Juice Oil 2000 Ml
  • PET Water Bottle Blowing Equipment Eceng K4 Energy Juice Oil 2000 Ml
  • PET Water Bottle Blowing Equipment Eceng K4 Energy Juice Oil 2000 Ml
  • PET Water Bottle Blowing Equipment Eceng K4 Energy Juice Oil 2000 Ml
PET Water Bottle Blowing Equipment Eceng K4 Energy Juice Oil 2000 Ml
Product Details:
Place of Origin: Jiangsu, China
Brand Name: Eceng
Certification: CE ISO
Model Number: K4
Payment & Shipping Terms:
Minimum Order Quantity: 1set
Packaging Details: standard export wooden case or according to your requirements
Delivery Time: 60days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 500 Set/Sets per Year
Contact Now
Detailed Product Description
Bottle Volume(ml): 2000 Ml Blow Moulding Type: Stretch Blow Moulding
Rotary Cylinder Brand: SMC Key Selling Points: Automatic
Applicable Industries: Manufacturing Plant Machinery Test Report: Provided
Video Outgoing-inspection: Provided Warranty Of Core Components: 1 Year
High Light:

PET Water Eceng Bottle Blowing Equipment

,

K4 PET Bottle Blowing Equipment

,

PET 2000ml Bottle Blowing Machine

10000BPHPET Water Bottle Blowing Equipment Eceng K4 Energy Juice Oil 2000 Ml

PET Water Bottle Blowing Equipment Eceng K4 Energy Juice Oil 2000 Ml 0

Automatic 4 cavity plastic alcohol bottle stretch blow molding moulding machine
Kseries linear bottle blowing machine features:
1.stable and accurate running at high speed,adopt more stable and advanced microcomputer PLC control system.
2. production process is fully automated, with the advantages of low investment, high efficiency, easy operation, simple maintenance and safety.
3. suitable for flexible production of quantity and various bottle shape,wide range of applications,meet customer needs.
4. manual and automatic methods of operation, human-machine interface control, simple operation.
5. servo transmission system, high positioning accuracy, fast speed stability and good reliability.
6. less than 0.2% scrap rate for finished bottle .



PET Water Bottle Blowing Equipment Eceng K4 Energy Juice Oil 2000 Ml 1

Model Eceng K4

Bottle type specification



Cavity 4
Max.volume 200ml-2000ml
Bottle mouth maximum overall diameter 25-29mm NECK
Bottle biggest diameter 100mm
Bottle maximum height 330mm

Capacity specification



Theory output 8000-10000BPH
Bottle type volume 600ML
Bottle type weight 13.5g
Bottle type Round
Power specification Light tube quantity 16pcs
Light tube power 1.25KW
Maximum heating power 20KW
All electric machine installation 29KW
Actual consumption 30%--60%

Air pressure specification



Work pressure 5-6kg/cm2
Blow bottle pressure 25-45kg/cm2
Higher -pressure gas consumption 6000Ltr/min
Forzen water specification Work pressure 5-6 kg/cm2
Temperature range 10℃
Consumption 8000kcal/hr
Forzen water flow 120L/min
Machine specification Machine size 3.6*1.6*1.9
Machine weight 4.3ton


K4 auto energy juice oil beverage PET plastic Snack food the oval bottle blow moulding molding machine equipment line.K series is a stable two-step blow-down stretch automatic blowing machine.It can be used from 4 cavity to 12 cavity with a speed of 1500 bottles per hour (750 ml plastic bottles),max volume 2L plastic bottle,suitable for blowing any kind of carbonated beverage bottle,sparkling beverage bottle,pure water bottle, mineral water bottle,fruit juice beverage bottle,cosmetic bottles,large diameter bottles, high temperature resistance bottles and other packaging bottles.

PET Water Bottle Blowing Equipment Eceng K4 Energy Juice Oil 2000 Ml 2

PET Water Bottle Blowing Equipment Eceng K4 Energy Juice Oil 2000 Ml 3

PET Water Bottle Blowing Equipment Eceng K4 Energy Juice Oil 2000 Ml 4

PET Water Bottle Blowing Equipment Eceng K4 Energy Juice Oil 2000 Ml 5

PET Water Bottle Blowing Equipment Eceng K4 Energy Juice Oil 2000 Ml 6

PET Water Bottle Blowing Equipment Eceng K4 Energy Juice Oil 2000 Ml 7

Zhangjiagang Eceng Machinery Co., Ltd is founded in 2007,We manufacture fully-automatic PET bottle blowing machine, injection mold,blowing mold etc.,suitable for 5ml-50L plastic bottles,water bottles,carbonated beverage bottles,oil bottles,cosmetics bottles.We can equip machine from 1-12 cavity,output from hundreds bottles to 36,000 bottles/hour,also provide full set of production system from preform production,bottle blowing,filling to final packaging.
So far Eceng machinery have provided more than 2050 sets machines for more than 170 countries in the world.Our equipments are highly estimated by the clients, and are well known at home and abroad.We sincerely hope to establish business relationship with friends all over the world.



PET Water Bottle Blowing Equipment Eceng K4 Energy Juice Oil 2000 Ml 8
PET Water Bottle Blowing Equipment Eceng K4 Energy Juice Oil 2000 Ml 9

PET Water Bottle Blowing Equipment Eceng K4 Energy Juice Oil 2000 Ml 10
PET Water Bottle Blowing Equipment Eceng K4 Energy Juice Oil 2000 Ml 11

PET Water Bottle Blowing Equipment Eceng K4 Energy Juice Oil 2000 Ml 12

Normally the inner package, we will packed by the stretch film. Outer package we will use the export woodencase. Mostly we deliver the goods by sea as the freight is most reasonable in this way.

PET Water Bottle Blowing Equipment Eceng K4 Energy Juice Oil 2000 Ml 13



PET Water Bottle Blowing Equipment Eceng K4 Energy Juice Oil 2000 Ml 14
