2 Cavity Semi Automatic Blow Molding Machine PET Preform Water Bottle YC-2L-2

2 Cavity Semi Automatic Blow Molding Machine PET Preform Water Bottle YC-2L-2

2 Cavity Semi Automatic Blow Molding Machine PET Preform Water Bottle YC-2L-2
2 Cavity Semi Automatic Blow Molding Machine PET Preform Water Bottle YC-2L-2
2 Cavity Semi Automatic Blow Molding Machine PET Preform Water Bottle YC-2L-2
Product Details:
Place of Origin: Jiangsu, China
Brand Name: Eceng
Certification: CE,ISO
Model Number: YC-2L-2
Payment & Shipping Terms:
Minimum Order Quantity: 1set
Packaging Details: Wooden package
Delivery Time: 45days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 20 Set/Sets per Month
Contact Now
Detailed Product Description
Pet Making Machine: Semi Auto Pet Bottle Blowing Machine Bottle Volume(ml): 2000 Ml
Blow Moulding Type: Stretch Blow Moulding Voltage: 380V, 50HZ, 3PHASE
Dimension(L*W*H): 1.46*0.58*1.8(m) Hollow Part Volume: 2l
Automation: Semi-automatic Warranty: 1 Year, One Year
High Light:

Semi Automatic Blow Molding Machine

,

2 Cavity PET Blow Molding Machine

,

PET Blow Molding Machine 3PHASE

2 Cavity Semi Automatic PET Preform Water Juice Bottle Blow Molding Machine YC-2L-2, Low Power Consumption
Product Description

Our Advantages:
1.Perfect function with economic investment.. Perfect function with economic investment.
2.Small size and compact construction withno space waste.
3.Easy to operate and maintaln, operation by one person.
4.Saving power and uneasy to worn out.
5.Adopting new double crank io lock mould, the cross fixed Providing high pressure bliowing system.
6.We can provide preforms and variousboth &cap molds from3 gallon to 5 gallon botles to met Customer's requirements.

2 Cavity Semi Automatic Blow Molding Machine PET Preform Water Bottle YC-2L-2 0



Main machine (blower + oven)

Item YC-2L-2
Product Spec Max. product volume(L/cav) 2L
Max. preform neck size(mm) 100
Max. product diameter(mm) 180
Max. product height (mm) 300
Cavities 2
Blow molding part Die force (KN) 100
Die stroke (mm) 270
Max. mould size(mm) 390*345
Mould thickness Adjustable
Mould spacing(mm) Adjustable
Max. pulling stroke(mm) 400
Operation pressure(Mpa) 0.8-1.0

Operation air pressure consumption

(1tr/min)

200
Blow pressure(Mpa) 1.2-2.8
Blow air pressure consumption (1tr/min) 300
Output(pcs/h) 800
Machine size(LxWxH)(m) 1.46*0.58*1.8
Machine weight(KG) 650
Oven Temperature grade(rate) 8
Heating time(S) 90-200
Voltage(V) 220 or as your request
Frequency(HZ) 50/60
Total power(KW) 16
Oven Size (LxWxH) 1.35*0.55*1.15
Oven weight (KG)

300







2 Cavity Semi Automatic Blow Molding Machine PET Preform Water Bottle YC-2L-2 1

2 Cavity Semi Automatic Blow Molding Machine PET Preform Water Bottle YC-2L-2 22 Cavity Semi Automatic Blow Molding Machine PET Preform Water Bottle YC-2L-2 4



YC series semi-automatic bottle blowing machine is controlled by microcomputer,control the technical parameters more accurately.PET bottle blowing machine is simple and safe to operate.It only requires one person and does not require special training.YC series PET blow molding machine is suitable for blow molding of plastic packaging bottles such as carbonated beverage bottles, mineral water bottles, hot filling bottles and cosmetic bottles. It is suitable for the production of small beverage companies and daily chemical product companies.

Adopt infrared lamp heating, strong penetration, preform rotation heating, track revolution, heating evenly, fast and reliable; heating lamp,reflector width and height can be adjusted to suit preform heating of different structure,with automatic temperature-removal device to ensure the constant temperature of oven.

Specially designed high rigidity composite mold structure, wide applicability, suitable for various types of mold thickness, easy to adjust and save energy, less air demand, precision polished spindle, equipped with photoelectric sensor, low noise,rapid response, long working hours , stable performance,ensure stable operation.

YC linear bottle blowing machine adopts advanced microcomputer PLC control system, stable performance,manual type and fully automatic type.



2 Cavity Semi Automatic Blow Molding Machine PET Preform Water Bottle YC-2L-2 6



2 Cavity Semi Automatic Blow Molding Machine PET Preform Water Bottle YC-2L-2 8

2 Cavity Semi Automatic Blow Molding Machine PET Preform Water Bottle YC-2L-2 9
