Blow your bottle, Shape your dream
 |
| Place of Origin: | Jiangsu, China |
| Brand Name: | Eceng |
| Certification: | CE SGS ISO |
| Model Number: | Q6000 |
| Minimum Order Quantity: | 1set |
|---|---|
| Packaging Details: | standard export wooden case or according to your requirements |
| Delivery Time: | 45days |
| Payment Terms: | L/C, T/T, Western Union |
| Supply Ability: | 500 Set/Sets per Year |
| Plastic Processed: | PET | Max.Bottle Height(mm): | 330 Mm |
|---|---|---|---|
| Neck Diameter(mm): | 28 Mm | Max.Bottle Diameter(mm): | 105 Mm |
| Bottle Volume(ml): | 2000 Ml | Condition: | New |
| Application: | Bottle | Blow Moulding Type: | Stretch Blow Moulding |
| High Light: | Stretch Pet Blow Moulding Machine,Eceng Q6000 Pet Blow Moulding Machine,Pet 4cavity Blow Moulding Machine |
||
Eceng Q6000 Stretch Pet Blow Moulding Machine 4cavity For Mineral Water Bottle Line
| Model | Q6000 | |
|
Bottle type specification
|
Cavity | 4 |
| Max.volume | 2L | |
| Bottle mouth maximum overall diameter | 28-38mm | |
| Bottle biggest diameter | 105mm | |
| Bottle maximum height | 330mm | |
| Production specification | Theoretical output | 6000BPH |
| Bottle type capacity | 500ML | |
| Bottle type weight | 17g | |
| Bottle type | circular | |
| Power specification | Light tube quantity | 32pcs |
| Light tube power | 1.5KW | |
| Maximum heating power | 48KW | |
| All electric machine installation | 52KW | |
| Actual consumption | 40%--70% | |
|
Air pressure specification
|
Work pressure | 7-9kg/cm2 |
| Low-pressure gas consumption | 1000L/min | |
| Blow bottle pressure | 25-35kg/cm2 | |
| Higher -pressure gas consumption | 3000Ltr/min | |
|
Air pressure specification
|
Work pressure | 5-6 kg/cm2 |
| Temperature range | 10℃ | |
| Consumption | 8000kcal/hr | |
| Forzen water flow | 138L/min | |
|
Machine specification
|
Machine size | 4.1x1.6x1.9 |
| Machine weight | 3.9ton | |
Eceng Q6000 4cavity stretch pet blow moulding machine is a high-quality equipment that enables efficient and accurate production of mineral water bottles,edible oil bottle,ruit juice bottle,carbonated drinks bottle,etc.
This machine is designed to ensure consistent and reliable performance, with 4cavitys, Eceng Q6000 machine boasts of high efficiency and low maintenance, making it the perfect solution for manufacturers looking for reliable production equipment.
Whether you are a small or large-scale manufacturer, the Eceng Q6000 4cavity stretch pet blow moulding machine is the go-to option for making high quality, durable and long-lasting bottles for your customers.
Zhangjiagang Eceng Machinery Co., Ltd is founded in 2007,We manufacture fully-automatic PET bottle blowing machine, injection mold,blowing mold etc.,suitable for 5ml-50L plastic bottles,water bottles,carbonated beverage bottles,oil bottles,cosmetics bottles.We can equip machine from 1-12 cavity,output from hundreds bottles to 36,000 bottles/hour,also provide full set of production system from preform production,bottle blowing,filling to final packaging.
So far Eceng machinery have provided more than 2050 sets machines for more than 170 countries in the world.Our equipments are highly estimated by the clients, and are well known at home and abroad.We sincerely hope to establish business relationship with friends all over the world.
our advantage:1. Resonable price;2. Good after service;3. experienced skilled workers and professional engineers;4. Good quality ,excellent service ,long life mould;5. on time delivery time;6.our engineers can be online for 24 hours to serve you.
Normally the inner package, we will packed by the stretch film. Outer package we will use the export woodencase. Mostly we deliver the goods by sea as the freight is most reasonable in this way.
Q:Your company is a trading company or a direct factory?
A:We are a direct factory which locates in Zhangjiagang city.
Q:All of your products are made by yourself or compacted via purchasing the others?
A:We have independent technical team who focus on making machines,all the products are made by our technical team.
Q:What is the ability of your factory?
A:About 80 lines per year.
Q:Do you have any other services about your products?
A:We have a lot of experience on making projects and specifications for our clients,also we have a fixed service system.
Q:How do you make the quotation for clients?
A:The price depends on quality and performance but the clients should be satisfied first.
