Beverage Juice Bottle Blow Molding Machine 380V Eceng K4 Auto Energy Conservation

Beverage Juice Bottle Blow Molding Machine 380V Eceng K4 Auto Energy Conservation

  • Beverage Juice Bottle Blow Molding Machine 380V Eceng K4 Auto Energy Conservation
  • Beverage Juice Bottle Blow Molding Machine 380V Eceng K4 Auto Energy Conservation
  • Beverage Juice Bottle Blow Molding Machine 380V Eceng K4 Auto Energy Conservation
  • Beverage Juice Bottle Blow Molding Machine 380V Eceng K4 Auto Energy Conservation
  • Beverage Juice Bottle Blow Molding Machine 380V Eceng K4 Auto Energy Conservation
  • Beverage Juice Bottle Blow Molding Machine 380V Eceng K4 Auto Energy Conservation
Beverage Juice Bottle Blow Molding Machine 380V Eceng K4 Auto Energy Conservation
Product Details:
Place of Origin: Jiangsu, China
Brand Name: Eceng
Certification: CE ISO
Model Number: K4
Payment & Shipping Terms:
Minimum Order Quantity: 1set
Price: $35,800.00/Sets 1-1 Sets
Packaging Details: standard export wooden case or according to your requirements
Delivery Time: 60days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 500 Set/Sets per Year
Contact Now
Detailed Product Description
Bottle Volume(ml): 2000 Ml Application: Bottle
Blow Moulding Type: Stretch Blow Moulding Voltage: 380V,50HZ
Dimension(L*W*H): 3.3*1.6*1.9m Hollow Part Volume: 2L
PLC Brand: DELTA Video Outgoing-inspection: Provided
High Light:

Beverage Juice Bottle Blow Molding Machine

,

Eceng K4 Bottle Blow Molding Machine

,

380V Blow Bottle Molding Machine

Eceng K4 Auto Energy Conservation Beverage Juice Bottle Blow Molding Machine
Beverage Juice Bottle Blow Molding Machine 380V Eceng K4 Auto Energy Conservation 0
Beverage Juice Bottle Blow Molding Machine 380V Eceng K4 Auto Energy Conservation 2
specification
             Model                                                                    K4






Bottle type specification
Cavity
4

Max.volume
2L

Bottle mouth maximum overall diameter
25-29mm

Bottle biggest diameter
100mm

Bottle maximum height
330mm


Capacity specification
Theory output
6000BPH

Bottle type volume
600ML

Bottle type weight
13.5g

Bottle type
Round



Power specification
Light tube quantity
16pcs

Light tube power
1.25KW

Maximum heating power
20KW

All electric machine installation
29KW

Actual consumption
30%--60%


Air pressure specification
Work pressure
5-6kg/cm2

Blow bottle pressure
25-45kg/cm2

Higher -pressure gas consumption
6000Ltr/min


Air pressure specification
Work pressure
5-6 kg/cm2

Temperature range
10℃

Consumption
6000kcal/hr

Forzen water flow
120L/min

Machine specification
Machine size
3.6x1.6x1.9

Machine weight
4.3ton

K series is a stable two-step blow-down stretch automatic blowing machine.It can be used from 4 cavity to 12 cavity with a speed of 2500 bottles per hour,max volume 2L plastic bottle.

Eceng K4 Auto Energy Conservation Beverage Juice Bottle Blow Molding Machine is a revolutionary piece of technology that has taken the beverage industry by storm. With its advanced design and energy-saving features, it is the perfect solution for large-scale beverage manufacturers who are looking to reduce their carbon footprint and increase efficiency without compromising on quality.

This state-of-the-art machine uses the latest technologies to produce high-quality beverage and juice bottles at a much faster rate than traditional blow molding machines. Its fully automated system ensures that every bottle is manufactured to the highest standards of precision and accuracy, making it the ideal choice for businesses looking for a reliable and cost-effective solution.

One of the key features of the Eceng K4 Auto Energy Conservation Beverage Juice Bottle Blow Molding Machine is its energy-saving capabilities. This machine is designed to use less power than other machines of its type, making it an eco-friendly option for businesses looking to reduce their carbon footprint.

In addition, this machine is incredibly versatile and can be used to produce a wide range of bottle sizes and shapes. This means that businesses can easily customize their bottle designs to suit their specific needs and market demands.

Overall, the Eceng K4 Auto Energy Conservation Beverage Juice Bottle Blow Molding Machine is a game-changer for the beverage industry. It is a reliable, efficient, and eco-friendly option that can help businesses to reduce their costs, increase their productivity, and improve their environmental impact.

Beverage Juice Bottle Blow Molding Machine 380V Eceng K4 Auto Energy Conservation 4
Automatic 4 cavity plastic alcohol bottle stretch blow molding moulding machine
Kseries linear bottle blowing machine features:
1.stable and accurate running at high speed,adopt more stable and advanced microcomputer PLC control system.
2. production process is fully automated, with the advantages of low investment, high efficiency, easy operation, simple maintenance and safety.
3. suitable for flexible production of quantity and various bottle shape,wide range of applications,meet customer needs.
4. manual and automatic methods of operation, human-machine interface control, simple operation.
5. servo transmission system, high positioning accuracy, fast speed stability and good reliability.
6. less than 0.2% scrap rate for finished bottle .
blowing mould
Beverage Juice Bottle Blow Molding Machine 380V Eceng K4 Auto Energy Conservation 6
Beverage Juice Bottle Blow Molding Machine 380V Eceng K4 Auto Energy Conservation 8
Company Introduction
Beverage Juice Bottle Blow Molding Machine 380V Eceng K4 Auto Energy Conservation 10
Beverage Juice Bottle Blow Molding Machine 380V Eceng K4 Auto Energy Conservation 12
Beverage Juice Bottle Blow Molding Machine 380V Eceng K4 Auto Energy Conservation 14
Packing&Shipping
Beverage Juice Bottle Blow Molding Machine 380V Eceng K4 Auto Energy Conservation 16
Beverage Juice Bottle Blow Molding Machine 380V Eceng K4 Auto Energy Conservation 18
Normally the inner package, we will packed by the stretch film. Outer package we will use the export woodencase. Mostly we deliver the goods by sea as the freight is most reasonable in this way.
