High Speed Linear Stretch Blowing Machine 8 Cavity Automatic For Filling Bottles 16000BPH

High Speed Linear Stretch Blowing Machine 8 Cavity Automatic For Filling Bottles 16000BPH

High Speed Linear Stretch Blowing Machine 8 Cavity Automatic For Filling Bottles 16000BPH
High Speed Linear Stretch Blowing Machine 8 Cavity Automatic For Filling Bottles 16000BPH
High Speed Linear Stretch Blowing Machine 8 Cavity Automatic For Filling Bottles 16000BPH
Product Details:
Place of Origin: Jiangsu, China
Brand Name: eceng
Certification: CE/ISO
Model Number: k8
Payment & Shipping Terms:
Minimum Order Quantity: 1set
Price: $40,000.00 - $70,000.00/Sets
Packaging Details: packed by wooden pallet or as customer request
Delivery Time: 60days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 15 Set/Sets per Month
Contact Now
Detailed Product Description
Plastic Processed: PET Condition: New
Power (kW): 65 Warranty: 1 Year
Warranty Of Core Components: 1 Year Automatic: YES
Service: Full Technical Training Port: Shanghai/Ningbo
High Light:

High Speed Linear Stretch Blowing Machine

,

8 Cavity Linear Stretch Blowing Machine

,

16000 BPH Stretch Blowing Bottles Machine

8 Cavity Automatic High Speed Linear Stretch Blowing Machine for Hot Filling Bottles 12000-16000BPH



High Speed Linear Stretch Blowing Machine 8 Cavity Automatic For Filling Bottles 16000BPH 0

k series linear bottle blowing machines are used in the production of PET water bottles, hot filling bottles, carbonated beverage bottles, edible oil bottles, and pesticide bottles.Eceng Machinery's Q series linear bottle blowing machine stretches preforms by using a servo motor-controlled stretch rod. The advantage is that it can be stretched in sections,and positioning of the preform is at first in order to ensure the verticality of the preforms during stretching, then secondary stretching.Ensure the uniformity and consistency of each preform stretching.At the same time,bottle blowing machine has a fast stretching speed and precise position.

High Speed Linear Stretch Blowing Machine 8 Cavity Automatic For Filling Bottles 16000BPH 2



Item K4 K6 K8
Cavity 4 6 8
Theory output 6000-8500BPH 9000-12000 12000-16000
Max.volume 2L 2L 2L
Bottle mouth maximum overall diameter 28-38mm 28-38mm 28-38mm
Bottle biggest diameter 100mm 100mm 100mm
Bottle maximum height 330mm 330mm 330mm
Light tube quantity 16pcs 32pcs 32pcs
Light tube power 1.25KW 1.25KW 1.5KW
Maximum heating power 20KW 40KW 48KW
All electric machine installation 29KW 49KW 65KW
Actual consumption 30%-60% 30%-60% 30%-60%
Work pressure 5-6kg/c 5-6kg/c 5-6kg/c
Blow bottle pressure 25-45kg/c 25-45kg/c 25-45kg/c
Higher -pressure gas consumption 6000Ltr/min 8000Ltr/min 12000Ltr/min
Work pressure 5-6 kg/c 5-6 kg/c 5-6 kg/c
Temperature range 10ºC 10ºC 10ºC
Consumption 8000kcal/hr 8000kcal/hr 12000kcal/hr
Forzen water flow 30L/min 88L/min 88L/min
Size of the machine 3.6*1.6*1.9(m) 4.8x1.6x1.9 5.78x1.6x1.9
Weight of the machine 4.3ton 6.1ton 7.45ton


High Speed Linear Stretch Blowing Machine 8 Cavity Automatic For Filling Bottles 16000BPH 4

K8 Fully Automatic PET Stretch Blow Moulding Machine with 8 Cavity is an innovative and high-performance solution for businesses looking to streamline their packaging process and increase output. With a capacity ranging from 12,000 to 16,000 bottles per hour, this machine offers unparalleled efficiency and productivity.

One of the key benefits of the K8 is the fully automated process, which reduces the need for manual labor and increases safety in the workplace. The machine is equipped with advanced technology that ensures consistent and reliable results, even at high speeds. This makes it an ideal choice for businesses looking to optimize their production line and reduce costs.

Moreover, the K8 is highly versatile and can handle a range of PET bottle sizes and shapes, making it a desirable option for businesses looking to diversify their product offerings. With its user-friendly interface, the machine is easy to operate and requires minimal training.

In conclusion, the K8 Fully Automatic PET Stretch Blow Moulding Machine is an excellent investment for businesses looking to improve their packaging process and increase output. Its advanced technology, high efficiency, and versatility make it a top choice for manufacturers in a range of industries.

 High Speed Linear Stretch Blowing Machine 8 Cavity Automatic For Filling Bottles 16000BPH 6

Auto-loader improves working efficiency,accurate transportation,reliable and durable,raw materials are completely free of moisture,pollution,foreign matter, and loss during feeding process.Realize transportation process of feeding process, avoid danger of high-altitude feeding, reduce labor intensity and increase production efficiency.

High Speed Linear Stretch Blowing Machine 8 Cavity Automatic For Filling Bottles 16000BPH 8

New clamping system,upgraded on the basis of the original ones,increase mould clamping speed and output,greatly reduce mold clamping noise.

High Speed Linear Stretch Blowing Machine 8 Cavity Automatic For Filling Bottles 16000BPH 10

Adopt infrared lamp heating, strong penetration, preform rotation heating, track revolution, heating evenly, fast and reliable; heating lamp,reflector width and height can be adjusted to suit preform heating of different structure,with automatic temperature-removal device to ensure the constant temperature of oven.

High Speed Linear Stretch Blowing Machine 8 Cavity Automatic For Filling Bottles 16000BPH 12

k series bottle blowing machine adopts advanced microcomputer PLC control system, stable performance; servo transmission system, high positioning accuracy, fast speed, stable and reliable.



High Speed Linear Stretch Blowing Machine 8 Cavity Automatic For Filling Bottles 16000BPH 14

High Speed Linear Stretch Blowing Machine 8 Cavity Automatic For Filling Bottles 16000BPH 15



High Speed Linear Stretch Blowing Machine 8 Cavity Automatic For Filling Bottles 16000BPH 16



High Speed Linear Stretch Blowing Machine 8 Cavity Automatic For Filling Bottles 16000BPH 17

 High Speed Linear Stretch Blowing Machine 8 Cavity Automatic For Filling Bottles 16000BPH 19

High Speed Linear Stretch Blowing Machine 8 Cavity Automatic For Filling Bottles 16000BPH 21High Speed Linear Stretch Blowing Machine 8 Cavity Automatic For Filling Bottles 16000BPH 23

Q:Your company is a trading company or a direct factory?

A:We are a direct factory which locates in Zhangjiagang city.

Q:All of your products are made by yourself or compacted via purchasing the others?

A:We have independent technical team who focus on making machines,all the products are made by our technical team.

Q:What is the ability of your factory?

A:About 80 lines per year.

Q:Do you have any other services about your products?

A:We have a lot of experience on making projects and specifications for our clients,also we have a fixed service system.

Q:How do you make the quotation for clients?

A:The price depends on quality and performance but the clients should be satisfied first.
