| Place of Origin: | Jiangsu, China |
| Brand Name: | Eceng |
| Certification: | CE ISO |
| Model Number: | K12 |
| Minimum Order Quantity: | 1set |
|---|---|
| Price: | $25,000.00 - $40,000.00/Sets |
| Packaging Details: | standard export wooden case or according to your requirements |
| Delivery Time: | 60days |
| Payment Terms: | L/C, T/T, Western Union |
| Supply Ability: | 500 Set/Sets per Year |
| Plastic Processed: | PET | Application: | Bottle |
|---|---|---|---|
| Blow Moulding Type: | Stretch Blow Moulding | Automation: | Automatic |
| Key Selling Points: | Automatic Blow Molding Machine | Warranty Of Core Components: | 1 Year |
| Applicable Industries: | Manufacturing Plant | Model Number: | K12 |
| High Light: | Stretch Water Bottle Blowing Moulding Machine,12 Cavity Bottle Blowing Moulding Machine,K12 Stretch Bottle Blowing Machine |
||
12 Cavity High Speed Water Bottle Blowing Machine 22000-26000BPH China Manufacturer
Product Parameters
| Model K12 | ||
|
Bottle type specification
|
Cavity | 12 |
| Max.volume | 200ml-750ml | |
| Bottle mouth maximum overall diameter | 25-29mm NECK | |
| Bottle biggest diameter | 75mm | |
| Bottle maximum height | 180mm | |
|
Capacity specification
|
Theory output | 22000~26000BPH |
| Bottle type volume | 600ML | |
| Bottle type weight | 13.5g | |
| Bottle type | Round | |
| Power specification | Light tube quantity | 32pcs |
| Light tube power | 1.75KW | |
| Maximum heating power | 56KW | |
| All electric machine installation | 71KW | |
| Actual consumption | 30%--60% | |
|
Air pressure specification
|
Work pressure | 5-6kg/cm2 |
| Blow bottle pressure | 25-45kg/cm2 | |
| Higher -pressure gas consumption | 24000Ltr/min | |
| Forzen water specification | Work pressure | 5-6 kg/cm2 |
| Temperature range | 10℃ | |
| Consumption | 12000kcal/hr | |
| Temperature range | 10℃ | |
| Forzen water flow | 180L/min | |
| Machine specification | Machine size | 9.0x2.0x2.3 |
| Machine weight | 10.0ton | |
1. Our 12 cavity water bottle blowing machine is a high-speed production line that can meet the output demand of 22000 to 26000 bottles per hour. As a leading China manufacturer of bottle blowing machines, we deliver quality and efficiency to your production line.
2. Designed with advanced technology, this 12 cavity water bottle blowing machine boasts of high precision, durability, and reliability. It is suitable for blowing PET bottles of various shapes and sizes, making it ideal for use in the cosmetics, food, and beverage industries.
3. With a fully automated system, this 12 cavity water bottle blowing machine offers unmatched efficiency while reducing labor costs. It is easy to operate, requiring minimal human intervention, and comes with safety features to ensure a safe working environment.
4. Our 12 cavity water bottle blowing machine delivers consistent quality and accuracy in each production cycle, making it a cost-effective solution for your business. It is fully customizable to meet your specific production needs, and our team of experts is available to provide technical support and assistance.
5. Invest in our 12 cavity water bottle blowing machine today and enjoy reduced machine downtime, increased production efficiency, and improved product quality. As a reliable China manufacturer, we offer competitive pricing, fast delivery, and excellent after-sales service to ensure your satisfaction.
