J4 Plastic Jar Capsule Blow Molding Machine 4Cavity From China Factory

J4 Plastic Jar Capsule Blow Molding Machine 4Cavity From China Factory

J4 Plastic Jar Capsule Blow Molding Machine 4Cavity From China Factory
J4 Plastic Jar Capsule Blow Molding Machine 4Cavity From China Factory
J4 Plastic Jar Capsule Blow Molding Machine 4Cavity From China Factory
Product Details:
Place of Origin: CHINA
Brand Name: ECENG
Certification: CE SGS ISO
Model Number: jar blowing machine
Payment & Shipping Terms:
Minimum Order Quantity: One
Price: Negotiable
Packaging Details: film/wooden
Delivery Time: 45days
Payment Terms: TT LC western Union
Supply Ability: 10sets Per month
Contact Now
Detailed Product Description
Model Number: J Series Weight: 2.5ton
Capacity: High Color: Customized
Control System: PLC Material: Plastic
Molding Method: Blow Molding
High Light:

Plastic Jar Capsule Blow Molding Machine

,

4Cavity Jar Capsule Blow Molding Machine

,

J4 Jar Blow Molding Machine

Reliable J4 4Cavity Plastic Jar Capsule Blow Molding Machine Supplier from China Factory                                 Specification


Model

J4

Bottle type specification

Cavity

4

Theory output bph

2200-2400

Max.volum

2L

Bottle mouth maximum overall diameter

80mm

Bottle biggest diameter

100mm

Bottle maximum height

330mm

Power specification

Light tube quantity

32pcs

Light tube power

1KW

Maximum heating power

32KW

All electric machine installation

42KW

Actual consumption

30%--60%

Air pressure specification

Work pressure

7-9kg/cm2

Low-pressure gas consumption

1600L/min

Blow bottle pressure

25-35kg/cm2

Higher -pressure gas consumption

3000Ltr/min

Frozen water specification

Work pressure

7-9 kg/cm2

Temperature range

10℃

Consumption

8000kcal/hr

Forzen water flow

138L/min

Machine specification

Machine size

4.1x1.6x1.9

Machine weight

3.9ton

1. China Factory Made: This product is produced by a reliable and trusted China factory, ensuring high quality and efficiency.
2. 4 Cavity Plastic Jar Capsule Mold Blowing Machine J4: This machine is designed with 4 cavities, which allows for faster and more efficient production of plastic jars.
3. 2200-2400BPH: This machine has a high output rate of 2200-2400 bottles per hour, which ensures maximum productivity and profitability.
4. High-quality plastic jars: The plastic jars produced by this machine are of excellent quality and are suitable for a wide range of applications, including storing pills, powders, and liquids.
5. Cost-effective: This product is highly cost-effective, providing an affordable solution for businesses looking to produce high-quality plastic jars. So, if you are looking for a reliable and efficient plastic jar capsule mold blowing machine, China Factory's 4 Cavity Plastic Jar Capsule Mold Blowing Machine J4 is an excellent choice.
Product Photo

J4 Plastic Jar Capsule Blow Molding Machine 4Cavity From China Factory 0


J4 Plastic Jar Capsule Blow Molding Machine 4Cavity From China Factory 1

J4 Plastic Jar Capsule Blow Molding Machine 4Cavity From China Factory 2


J4 Plastic Jar Capsule Blow Molding Machine 4Cavity From China Factory 3

J4 Plastic Jar Capsule Blow Molding Machine 4Cavity From China Factory 4

J4 Plastic Jar Capsule Blow Molding Machine 4Cavity From China Factory 5
Working Process:

J4 Plastic Jar Capsule Blow Molding Machine 4Cavity From China Factory 6

Sketch Map:


J4 Plastic Jar Capsule Blow Molding Machine 4Cavity From China Factory 7


J4 Plastic Jar Capsule Blow Molding Machine 4Cavity From China Factory 8

J4 Plastic Jar Capsule Blow Molding Machine 4Cavity From China Factory 9

J4 Plastic Jar Capsule Blow Molding Machine 4Cavity From China Factory 10


J4 Plastic Jar Capsule Blow Molding Machine 4Cavity From China Factory 11

J4 Plastic Jar Capsule Blow Molding Machine 4Cavity From China Factory 12

J4 Plastic Jar Capsule Blow Molding Machine 4Cavity From China Factory 13


J4 Plastic Jar Capsule Blow Molding Machine 4Cavity From China Factory 14

J4 Plastic Jar Capsule Blow Molding Machine 4Cavity From China Factory 15

J4 Plastic Jar Capsule Blow Molding Machine 4Cavity From China Factory 16
Exhibition


J4 Plastic Jar Capsule Blow Molding Machine 4Cavity From China Factory 17

About Us


J4 Plastic Jar Capsule Blow Molding Machine 4Cavity From China Factory 18

Product packaging


J4 Plastic Jar Capsule Blow Molding Machine 4Cavity From China Factory 19
Packing
Conventional packaging: inside is wrapped with PE film outside is wooden box

J4 Plastic Jar Capsule Blow Molding Machine 4Cavity From China Factory 20
Delivery Conventional packaging: inside is wrapped with PE film outside is wooden box

J4 Plastic Jar Capsule Blow Molding Machine 4Cavity From China Factory 21

J4 Plastic Jar Capsule Blow Molding Machine 4Cavity From China Factory 22
J4 Plastic Jar Capsule Blow Molding Machine 4Cavity From China Factory 23
