CE ISO Semi Auto PET Bottle Stretch Blowing Machine 300KG YC-2L-4 2600-2800BPH

CE ISO Semi Auto PET Bottle Stretch Blowing Machine 300KG YC-2L-4 2600-2800BPH

  • CE ISO Semi Auto PET Bottle Stretch Blowing Machine 300KG YC-2L-4 2600-2800BPH
  • CE ISO Semi Auto PET Bottle Stretch Blowing Machine 300KG YC-2L-4 2600-2800BPH
  • CE ISO Semi Auto PET Bottle Stretch Blowing Machine 300KG YC-2L-4 2600-2800BPH
CE ISO Semi Auto PET Bottle Stretch Blowing Machine 300KG YC-2L-4 2600-2800BPH
Product Details:
Place of Origin: CHINA
Brand Name: ECENG
Certification: CE SGS ISO
Model Number: YC-2L-4
Payment & Shipping Terms:
Minimum Order Quantity: 1set
Price: Negotiable
Packaging Details: film/wooden
Delivery Time: 45days
Payment Terms: TT LC western Union
Supply Ability: 10sets Per month
Contact Now
Detailed Product Description
Model Number: YC-2L-4 Output: 2800bph
Weight: 300KG After-sales Service Provided: Engineers Available To Service Machinery Overseas
Name: Semi Automatic Pet Bottle Blowing Machine Blow Moulding Type: Stretch Blow Moulding
Certification: CE,ISO After Warranty Service: Online Support
High Light:

Semi Automatic Bottle Stretch Blowing Machine

,

Semi Automatic Bottle Blowing Machine 300KG

,

2800BPH Semi Auto Bottle Blowing Machine

High Quality Semi Auto PET Bottle Blowing Machine YC-2L-4, 2600-2800BPH

ain machine (blower + oven) Item YC-2L-4
Product Spec Max. product volume(L/cav) 2L
Max. preform neck size(mm) 100
Max. product diameter(mm) 180
Max. product height (mm) 300
Cavities 4
Blow molding part Die force (KN) 100
Die stroke (mm) 270
Max. mould size(mm) 390*345
Mould thickness Adjustable
Mould spacing(mm) Adjustable
Max. pulling stroke(mm) 400
Operation pressure(Mpa) 0.8-1.0

Operation air pressure consumption

(1tr/min)

200
Blow pressure(Mpa) 1.2-2.8
Blow air pressure consumption (1tr/min) 300
Output(pcs/h) 2600-2800(500ml bottle)
Machine size(LxWxH)(m) 1.46*0.58*1.8
Machine weight(KG) 650
Oven Temperature grade(rate) 8
Heating time(S) 90-200
Voltage(V) 220 or as your request
Frequency(HZ) 50/60
Total power(KW) 16
Oven Size (LxWxH) 1.35*0.55*1.15
Oven weight (KG) 300



Eceng YC-2L-4 Semi Auto PET Bottle Blowing Machine is an exceptional piece of equipment that is designed to meet the needs of the modern business. This incredible machine boasts a 4-cavity design and has a production capacity of 2600-2800BPH, making it an ideal choice for businesses in need of a high-volume, cost-effective solution.

One of the most impressive features of the YC-2L-4 Semi Auto PET Bottle Blowing Machine is its affordable price. Despite its exceptional performance capabilities, this machine is incredibly affordable and offers excellent value for money. This makes it an ideal choice for businesses of all sizes, from small startups to large corporations.

In addition to its cost-effective price, the YC-2L-4 Semi Auto PET Bottle Blowing Machine is also renowned for its stable performance. This ensures that you get consistent, reliable performance from your machine over the long term, reducing the need for costly repairs or replacements.

Overall, the YC-2L-4 Semi Auto PET Bottle Blowing Machine is a must-have piece of equipment for any business that requires a high-volume, cost-effective solution. If you are looking for a machine that offers exceptional performance, stability, and affordability, look no further than the YC-2L-4 Semi Auto PET Bottle Blowing Machine.

CE ISO Semi Auto PET Bottle Stretch Blowing Machine 300KG YC-2L-4 2600-2800BPH 0

CE ISO Semi Auto PET Bottle Stretch Blowing Machine 300KG YC-2L-4 2600-2800BPH 1

CE ISO Semi Auto PET Bottle Stretch Blowing Machine 300KG YC-2L-4 2600-2800BPH 2

CE ISO Semi Auto PET Bottle Stretch Blowing Machine 300KG YC-2L-4 2600-2800BPH 3
