K12 Water Bottle Blowing Moulding Machine 200ml-750ml 25-29mm NECK 22000-26000BPH

K12 Water Bottle Blowing Moulding Machine 200ml-750ml 25-29mm NECK 22000-26000BPH

K12 Water Bottle Blowing Moulding Machine 200ml-750ml 25-29mm NECK 22000-26000BPH
K12 Water Bottle Blowing Moulding Machine 200ml-750ml 25-29mm NECK 22000-26000BPH
K12 Water Bottle Blowing Moulding Machine 200ml-750ml 25-29mm NECK 22000-26000BPH
Product Details:
Place of Origin: Jiangsu, China
Brand Name: Eceng
Certification: CE ISO
Payment & Shipping Terms:
Minimum Order Quantity: 1set
Price: $25,000.00 - $40,000.00/Sets
Packaging Details: standard export wooden case or according to your requirements
Delivery Time: 60days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 500 Set/Sets per Year
Contact Now
Detailed Product Description
Model Number: K12 Plastic Processed: PET
Application: Bottle Blow Moulding Type: Stretch Blow Moulding
Automation: Automatic Key Selling Points: Automatic Blow Molding Machine
Warranty Of Core Components: 1 Year Applicable Industries: Manufacturing Plant
High Light:

K12 Water Bottle Blowing Machine

,

200ml Water Bottle Blowing Machine

,

Automatic Water Bottle Blowing Moulding Machine

K12 Water Bottle Blowing Machine, 200ml-750ml, 25-29mm NECK, 22000-26000BPH

Product Parameters

Model K12

Bottle type specification



Cavity 12
Max.volume 200ml-750ml
Bottle mouth maximum overall diameter 25-29mm NECK
Bottle biggest diameter 75mm
Bottle maximum height 180mm

Capacity specification



Theory output 22000~26000BPH
Bottle type volume 600ML
Bottle type weight 13.5g
Bottle type Round
Power specification Light tube quantity 32pcs
Light tube power 1.75KW
Maximum heating power 56KW
All electric machine installation 71KW
Actual consumption 30%--60%

Air pressure specification



Work pressure 5-6kg/cm2
Blow bottle pressure 25-45kg/cm2
Higher -pressure gas consumption 24000Ltr/min
Forzen water specification Work pressure 5-6 kg/cm2
Temperature range 10℃
Consumption 12000kcal/hr
Temperature range 10℃
Forzen water flow 180L/min
Machine specification Machine size 9.0x2.0x2.3
Machine weight 10.0ton



When producing high-quality water bottles,the machine you choose plays a crucial role. K12 Water Bottle Blowing Machine comes in – a tool designed to produce bottles of exceptional quality and durability, with capacities ranging from 200ml to 750ml.

This machine can accommodate neck sizes of 25-29mm, allowing you to produce bottles that fit perfectly with your specific requirements. With a production capacity of 22000-26000 bottles per hour (BPH), the K12 Water Bottle Blowing Machine is one of the most efficient devices on the market today.

The process of blowing plastic bottles using this machine is simple and straightforward.

The machine then uses air pressure to blow the plastic tube into a bottle shape, before finally cooling it down so that it sets into its new form. The process is incredibly fast and efficient, able to produce up to 26,000 bottles per hour, making it an ideal choice for large-scale production.

One of the strengths of the K12 Water Bottle Blowing Machine is its versatility. The machine is not only suitable for producing water bottles, but it is also possible to adjust the molds to produce other bottle shapes and sizes, such as juice bottles, sports drinks bottles, and more.

Another advantage of this machine is its ability to produce bottles that are highly resistant to impact and extreme temperatures, thanks to the high-quality plastic and strict quality control measures employed during production.

In summary, if you're looking to produce water bottles or similar products for the K12 industry, the K12 Water Bottle Blowing Machine is undoubtedly an excellent choice. With its high production capacity, durability, and flexibility, it is sure to meet your needs while also delivering quality products to your customers.


K12 Water Bottle Blowing Moulding Machine 200ml-750ml 25-29mm NECK 22000-26000BPH 0
K12 Water Bottle Blowing Moulding Machine 200ml-750ml 25-29mm NECK 22000-26000BPH 1K12 Water Bottle Blowing Moulding Machine 200ml-750ml 25-29mm NECK 22000-26000BPH 2
      Want to know more message , contact us with out hesitate ! Send us now !
K12 Water Bottle Blowing Moulding Machine 200ml-750ml 25-29mm NECK 22000-26000BPH 3

Company Information

K12 Water Bottle Blowing Moulding Machine 200ml-750ml 25-29mm NECK 22000-26000BPH 5

Our Services

K12 Water Bottle Blowing Moulding Machine 200ml-750ml 25-29mm NECK 22000-26000BPH 7

Packaging & Shipping

K12 Water Bottle Blowing Moulding Machine 200ml-750ml 25-29mm NECK 22000-26000BPH 9

——Transport&Payment——

K12 Water Bottle Blowing Moulding Machine 200ml-750ml 25-29mm NECK 22000-26000BPH 11

FAQ

K12 Water Bottle Blowing Moulding Machine 200ml-750ml 25-29mm NECK 22000-26000BPH 13
