Q3000 High Speed Water Bottle Blowing Moulding Machine 2 Cavity 3000BPH

Q3000 High Speed Water Bottle Blowing Moulding Machine 2 Cavity 3000BPH

Q3000 High Speed Water Bottle Blowing Moulding Machine 2 Cavity 3000BPH
Q3000 High Speed Water Bottle Blowing Moulding Machine 2 Cavity 3000BPH
Q3000 High Speed Water Bottle Blowing Moulding Machine 2 Cavity 3000BPH
Product Details:
Place of Origin: CHINA
Brand Name: ECENG
Certification: CE SGS ISO
Payment & Shipping Terms:
Minimum Order Quantity: One
Price: Negotiable
Packaging Details: film/wooden
Delivery Time: 45days
Payment Terms: TT LC western Union
Supply Ability: 10sets Per month
Contact Now
Detailed Product Description
Model Number: Q3000 Color: Orange
Output: 3000bph Weight: 2.5ton
BLOW MOULDING TYPE: Stretch Blow Moulding VOLTAGE: 380V, 50HZ, 3PHASE
AUTOMATION: Automatic VOLUME: 2l
High Light:

Q3000 Water Bottle Blowing Machine

,

3000BPH Water Bottle Blowing Machine

,

High Speed Bottle Blowing moulding Machine

Q3000 High Speed Water Bottle Blowing Moulding Machine 2 Cavity 3000BPH

Q3000 High Speed Water Bottle Blowing Moulding Machine 2 Cavity 3000BPH 0

Q3000 High Speed Water Bottle Blowing Moulding Machine 2 Cavity 3000BPH 1

Model Q3000
Bottle type specification Cavity 2
Theory output 3500
Max.volume 2L
Bottle mouth maximum overall diameter 80mm
Bottle biggest diameter 100mm
Bottle maximum height 330mm
Production specification Theoretical output 3000BPH
Bottle type capacity 500ML
Bottle type weight 17g
Bottle type circular
Power specifications Light tube quantity 32pcs
Light tube power 0.75KW
Maximum heating power 24KW
All electric machine installation 27KW
Actual consumption 19KW
Air pressure specification Work pressure 7-9kg/cm2
Low-pressure gas consumption 1000L/min
Blow bottle pressure 25-35kg/cm2
Higher -pressure gas consumption 1500Ltr/min
Frozen water specification Work pressure 5-6 kg/cm2
Temperature range 10℃
Consumption 5000kcal/hr
Frozen water flow 30L/min
Machine specification Size of the machine 2.25x1.6x1.7
Weight of the machine 2.5ton

Q3000 2-cavity 3000BPH bottle blow molding machine, the perfect choice for manufacturing high-quality water and juice bottles. With its impressive production capacity of 3000 bottles per hour, this machine is designed to increase efficiency without compromising on quality.

The dual-cavity design allows for simultaneous production, reducing production time and improving overall efficiency and profitability. The Q3000 machine ensures the production of strong, durable, and visually appealing bottles that meet the highest quality standards.

Whether you're a startup or an established manufacturer, investing in the Q3000 machine guarantees long-term dividends. Don't miss the opportunity to enhance your production and profitability. Contact us today to learn more about our bottle blow molding machines and take the first step toward success.

Q3000 High Speed Water Bottle Blowing Moulding Machine 2 Cavity 3000BPH 2

Fully Automatic Water Beverages Bottle Blowing Machine K8 8 Cavitys 16

Q3000 High Speed Water Bottle Blowing Moulding Machine 2 Cavity 3000BPH 4

Q3000 High Speed Water Bottle Blowing Moulding Machine 2 Cavity 3000BPH 5

Q3000 High Speed Water Bottle Blowing Moulding Machine 2 Cavity 3000BPH 6

Q3000 High Speed Water Bottle Blowing Moulding Machine 2 Cavity 3000BPH 7



Q3000 High Speed Water Bottle Blowing Moulding Machine 2 Cavity 3000BPH 8

Q3000 High Speed Water Bottle Blowing Moulding Machine 2 Cavity 3000BPH 9

Zhangjiagang Eceng Machinery Co., Ltd is founded in 2007,We manufacture fully-automatic PET bottle blowing machine, injection mold,blowing mold etc.,suitable for 5ml-50L plastic bottles,water bottles,carbonated beverage bottles,oil bottles,cosmetics bottles.We can equip machine from 1-12 cavity,output from hundreds bottles to 36,000 bottles/hour,also provide full set of production system from preform production,bottle blowing,filling to final packaging.
So far Eceng machinery have provided more than 2050 sets machines for more than 170 countries in the world.Our equipments are highly estimated by the clients, and are well known at home and abroad.We sincerely hope to establish business relationship with friends all over the world.



Q3000 High Speed Water Bottle Blowing Moulding Machine 2 Cavity 3000BPH 10
Q3000 High Speed Water Bottle Blowing Moulding Machine 2 Cavity 3000BPH 11

Q3000 High Speed Water Bottle Blowing Moulding Machine 2 Cavity 3000BPH 12
Q3000 High Speed Water Bottle Blowing Moulding Machine 2 Cavity 3000BPH 13



Q3000 High Speed Water Bottle Blowing Moulding Machine 2 Cavity 3000BPH 14

Normally the inner package, we will packed by the stretch film. Outer package we will use the export woodencase. Mostly we deliver the goods by sea as the freight is most reasonable in this way.

Q3000 High Speed Water Bottle Blowing Moulding Machine 2 Cavity 3000BPH 15

Q3000 High Speed Water Bottle Blowing Moulding Machine 2 Cavity 3000BPH 16

FAQ

Q:Your company is a trading company or a direct factory?

A:We are a direct factory which locates in Zhangjiagang city.

Q:All of your products are made by yourself or compacted via purchasing the others?

A:We have independent technical team who focus on making machines,all the products are made by our technical team.

Q:What is the ability of your factory?

A:About 80 lines per year.

Q:Do you have any other services about your products?

A:We have a lot of experience on making projects and specifications for our clients,also we have a fixed service system.

Q:How do you make the quotation for clients?

A:The price depends on quality and performance but the clients should be satisfied first.
