J5L2 5 Liter Automatic PET Jar Blowing Machine 1200-1300BPH 2 Cavity

J5L2 5 Liter Automatic PET Jar Blowing Machine 1200-1300BPH 2 Cavity

J5L2 5 Liter Automatic PET Jar Blowing Machine 1200-1300BPH  2 Cavity
J5L2 5 Liter Automatic PET Jar Blowing Machine 1200-1300BPH  2 Cavity
J5L2 5 Liter Automatic PET Jar Blowing Machine 1200-1300BPH  2 Cavity
Product Details:
Place of Origin: Jiangsu, China
Brand Name: Eceng
Certification: CE SGS ISO
Model Number: J5L2
Payment & Shipping Terms:
Minimum Order Quantity: 1set
Price: $26,800.00/Sets 1-1 Sets
Packaging Details: standard export wooden case or according to your requirements
Delivery Time: 45days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 500 Set/Sets per Year
Contact Now
Detailed Product Description
Plastic Processed: PET Bottle Volume(ml): 2000 Ml
Condition: New Blow Moulding Type: Stretch Blow Moulding
Dimension(L*W*H): 2.25*1.6*1.7m Automation: Automatic
Warranty: 1 Year Core Components: Bearing, Motor, Pump, Gear, PLC, Pressure Vessel
High Light:

Automatic PET Jar Blowing Machine

,

1300BPH PET Jar Blowing Machine

,

5 Liter Jar Blow Molding Machine

J5L2 5 Liter Automatic PET Jar Blowing Machine 1200-1300BPH 2 Cavity

J5L2 5 Liter Automatic PET Jar Blowing Machine 1200-1300BPH  2 Cavity 0

High Quality Servo Motor Wide Mouth 5 Liter 2 Cavity Automatic PET Jar Blowing Machine QJ5L2 Produce 1200-1300 Bottles Per Hour
PET jars have become increasingly popular for storing a variety of products ranging from food items to cosmetics. With this growing demand, the need for efficient and high-quality PET jar blowing machines has become a necessity.
Eceng QJ5L2 bottle making machine is equipped with a servo motor, which provides precise control over the blowing process, ensuring high-quality output. It features a wide mouth design, making it ideal for producing large-sized PET jars. Additionally, the 2-cavity design of the machine ensures that it can produce up to 1200-1300 jars per hour, making it highly efficient for large-scale production.
The machine also features automatic controls that enable easy operation and maintenance. It has an automatic preform loading system, which reduces manual intervention and ensures accurate preform placement. The machine also features an automatic lubrication system to reduce wear and tear, enhance performance, and improve lifespan.

J5L2 5 Liter Automatic PET Jar Blowing Machine 1200-1300BPH  2 Cavity 1

Item J5L2
Bottle type specification Cavity 2
Theory output 1200-1300
Max.volume 5L
Bottle mouth maximum overall DIdiameter 150mm
Bottle biggest diameter 180mm
Bottle maximum height 400mm
Power specifications Light tube quantity 32pcs
Light tube power 1.5KW
Maximum heating power 48KW
All electric machine installation 51KW
Actual consumption 35.7KW
Air pressure specification Work pressure 7-9kg/cm2
Low-pressure gas consumption 1600L/min
Blow bottle pressure 25-35kg/cm2
Higher -pressure gas consumption 3400Ltr/min
Forzen water specification Work pressure 5-6 kg/cm2
Temperature range 10℃
Consumption 6000kcal/hr
Forzen water flow 50L/min
Machine specification Size of the machine 4.7x1.6x1.9
Weight of the machine 3ton

Automatic China PET jar blowing machine J5L2 is specialized euipment designed for wide neck PET jars.It is high automatically,wide versatility and easy operation.It is especially suitable for the production of neck 50-180mm.J series bottle making machine is precisely positioned and adopts advanced microcomputer PLC control system,which is more stable.

J5L2 5 Liter Automatic PET Jar Blowing Machine 1200-1300BPH  2 Cavity 2

J linear bottle blowing machine adopts advanced microcomputer PLC control system, stable performance,manual type and fully automatic type.

J series linear bottle blowing machine features:
1.stable and accurate running at high speed,adopt more stable and advanced microcomputer PLC control system.
2. production process is fully automated, with the advantages of low investment, high efficiency, easy operation, simple maintenance and safety.
3. suitable for flexible production of quantity and various bottle shape,wide range of applications,meet customer needs.
4. manual and automatic methods of operation, human-machine interface control, simple operation.
5. servo transmission system, high positioning accuracy, fast speed stability and good reliability.

6. less than 0.2% scrap rate for finished bottle.

J5L2 5 Liter Automatic PET Jar Blowing Machine 1200-1300BPH  2 Cavity 3

J5L2 5 Liter Automatic PET Jar Blowing Machine 1200-1300BPH  2 Cavity 4



J5L2 5 Liter Automatic PET Jar Blowing Machine 1200-1300BPH  2 Cavity 5

J5L2 5 Liter Automatic PET Jar Blowing Machine 1200-1300BPH  2 Cavity 6

Zhangjiagang Eceng Machinery Co., Ltd is founded in 2007,We manufacture fully-automatic PET bottle blowing machine, injection mold,blowing mold etc.,suitable for 5ml-50L plastic bottles,water bottles,carbonated beverage bottles,oil bottles,cosmetics bottles.We can equip machine from 1-12 cavity,output from hundreds bottles to 36,000 bottles/hour,also provide full set of production system from preform production,bottle blowing,filling to final packaging.
So far Eceng machinery have provided more than 2050 sets machines for more than 170 countries in the world.Our equipments are highly estimated by the clients, and are well known at home and abroad.We sincerely hope to establish business relationship with friends all over the world.
J5L2 5 Liter Automatic PET Jar Blowing Machine 1200-1300BPH  2 Cavity 7
J5L2 5 Liter Automatic PET Jar Blowing Machine 1200-1300BPH  2 Cavity 8

our advantage:1. Resonable price;2. Good after service;3. experienced skilled workers and professional engineers;4. Good quality ,excellent service ,long life mould;5. on time delivery time;6.our engineers can be online for 24 hours to serve you.

J5L2 5 Liter Automatic PET Jar Blowing Machine 1200-1300BPH  2 Cavity 9

FAQ

Q:Your company is a trading company or a direct factory?

A:We are a direct factory which locates in Zhangjiagang city.

Q:All of your products are made by yourself or compacted via purchasing the others?

A:We have independent technical team who focus on making machines,all the products are made by our technical team.

Q:What is the ability of your factory?

A:About 80 lines per year.

Q:Do you have any other services about your products?

A:We have a lot of experience on making projects and specifications for our clients,also we have a fixed service system.

Q:How do you make the quotation for clients?

A:The price depends on quality and performance but the clients should be satisfied first.
