Eceng Oil Bottle Blowing Making Machine K5L4 1L-5L 3000-4000BPH

Eceng Oil Bottle Blowing Making Machine K5L4 1L-5L 3000-4000BPH

Eceng Oil Bottle Blowing Making Machine K5L4 1L-5L 3000-4000BPH
Eceng Oil Bottle Blowing Making Machine K5L4 1L-5L 3000-4000BPH
Eceng Oil Bottle Blowing Making Machine K5L4 1L-5L 3000-4000BPH
Product Details:
Place of Origin: Jiangsu, China
Brand Name: Eceng
Certification: CE ISO
Model Number: K5L4
Payment & Shipping Terms:
Minimum Order Quantity: 1set
Packaging Details: standard export wooden case or according to your requirements
Delivery Time: 30days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 500 Set/Sets per Year
Contact Now
Detailed Product Description
Bottle Volume(ml): 2000 Ml Condition: New
Application: Bottle Blow Moulding Type: Stretch Blow Moulding
Voltage: 380V,50HZ Dimension(L*W*H): 7.8*1.95*2.54m
Hollow Part Volume: 5L Applicable Industries: Manufacturing Plant
High Light:

Eceng Oil Bottle Blowing Making Machine

,

4000BPH Bottle Blowing Making Machine

,

K5L4 Bottle Blowing Machine

Eceng Oil Bottle Blowing Making Machine K5L4 1L-5L 3000-4000BPH
Eceng Oil Bottle Blowing Making Machine K5L4 1L-5L 3000-4000BPH 0
Eceng Oil Bottle Blowing Making Machine K5L4 1L-5L 3000-4000BPH 1

Model Eceng K5L4

Bottle type specification



Cavity 4
Max.volume 3L-5L
Bottle mouth maximum overall diameter 38-63mm
Bottle biggest diameter 185mm
Bottle maximum height 360mm

Capacity specification



Theory output 3500-4000BPH
Bottle type volume 5000ML
Bottle type weight 60g
Bottle type Round
Power specification Light tube quantity 32pcs
Light tube power 2KW
Maximum heating power 64KW
All electric machine installation 75KW
Actual consumption 30%--60%

Air pressure specification



Work pressure 5-6kg/cm2
Blow bottle pressure 25-45kg/cm2
Higher -pressure gas consumption 8000Ltr/min
Forzen water specification Work pressure 5-6 kg/cm2
Temperature range 10℃
Consumption 18000kcal/hr
Forzen water flow 120L/min
Machine specification Machine size 7.8*1.95*1.9
Machine weight 10.6ton


Eceng K5L4 professional 1L-5L Oil Bottle Blowing Making Machine, designed to meet the demands of high-speed and precision production. With a capacity of 3000-4000 bottles per hour (BPH), this advanced machinery is optimized for efficiency and performance.Eceng K5L4 is engineered to produce oil bottles ranging from 1L to 5L, offering versatility and adaptability for various packaging needs. Its professional 4-cavity design ensures consistent and reliable output.
Equipped with cutting-edge technology, this machine delivers exceptional results, maintaining the highest standards of bottle quality. Its streamlined operation and user-friendly interface make it an ideal choice for manufacturers seeking to optimize their production process.



Eceng Oil Bottle Blowing Making Machine K5L4 1L-5L 3000-4000BPH 2

Eceng Oil Bottle Blowing Making Machine K5L4 1L-5L 3000-4000BPH 3

Eceng Oil Bottle Blowing Making Machine K5L4 1L-5L 3000-4000BPH 4

Eceng Oil Bottle Blowing Making Machine K5L4 1L-5L 3000-4000BPH 5

Eceng Oil Bottle Blowing Making Machine K5L4 1L-5L 3000-4000BPH 6

Eceng Oil Bottle Blowing Making Machine K5L4 1L-5L 3000-4000BPH 7

Zhangjiagang Eceng Machinery Co., Ltd is founded in 2007,We manufacture fully-automatic PET bottle blowing machine, injection mold,blowing mold etc.,suitable for 5ml-50L plastic bottles,water bottles,carbonated beverage bottles,oil bottles,cosmetics bottles.We can equip machine from 1-12 cavity,output from hundreds bottles to 36,000 bottles/hour,also provide full set of production system from preform production,bottle blowing,filling to final packaging.
So far Eceng machinery have provided more than 2050 sets machines for more than 170 countries in the world.Our equipments are highly estimated by the clients, and are well known at home and abroad.We sincerely hope to establish business relationship with friends all over the world.Eceng Oil Bottle Blowing Making Machine K5L4 1L-5L 3000-4000BPH 8

Eceng Oil Bottle Blowing Making Machine K5L4 1L-5L 3000-4000BPH 9

Eceng Oil Bottle Blowing Making Machine K5L4 1L-5L 3000-4000BPH 10
Eceng Oil Bottle Blowing Making Machine K5L4 1L-5L 3000-4000BPH 11

Eceng Oil Bottle Blowing Making Machine K5L4 1L-5L 3000-4000BPH 12

Normally the inner package, we will packed by the stretch film. Outer package we will use the export woodencase. Mostly we deliver the goods by sea as the freight is most reasonable in this way.

Eceng Oil Bottle Blowing Making Machine K5L4 1L-5L 3000-4000BPH 13

Eceng Oil Bottle Blowing Making Machine K5L4 1L-5L 3000-4000BPH 14

FAQ

Q:Your company is a trading company or a direct factory?

A:We are a direct factory which locates in Zhangjiagang city.

Q:All of your products are made by yourself or compacted via purchasing the others?

A:We have independent technical team who focus on making machines,all the products are made by our technical team.

Q:What is the ability of your factory?

A:About 80 lines per year.

Q:Do you have any other services about your products?

A:We have a lot of experience on making projects and specifications for our clients,also we have a fixed service system.

Q:How do you make the quotation for clients?

A:The price depends on quality and performance but the clients should be satisfied first.
