24 Cavity Plastic Bottle Cap Making Machine Plastic Bottle Cap Compression Moulding Machine With High Speed 28000PCS/H

Eceng cap compression moulding machine

Eceng full automatic high speed cap compression moulding machine adopts hydraulic clamping principle, technic of rapid prototyping and mould release of low pressure, etc. to manufacture with continuous totation, widely used in the manufacture of bottle caps of carbonated beverage, mineral spring water, cosmetic products. The maximum productivity can reach 45000pcs one hour

	Model	24T
1	Output Capacity	20000-28000
2	Cap Diameter	20-60mm
3	Cap Height	10-30mm
4	Extrusion Heating Power	12KW
5	Extruder Motor Power	11KW
6	Cap Material	PE/PP
7	Cavity No.	24
8	Mold Compression Motor	3.5KW
9	Hydraulic System Power	17.5KW
10	Power Supply	380V/50HZ
11	Air Consumption	0.4m³/hr, 0.8Mpa
12	Machine Dimension	4.2*1.8*2.2m
13	Machine Weight	5000KG

Lower cost, higher productivity Output threefold vs. plastic injection Easy to assemble and disassemble Great cap quality, stable Grammage Quick mold change, less downtime Optimized design, user-friendly touch control Compact size, easy to handle

Water plastic closure

Cold Fill plastic closure

CSD BCPL plastic closure

1, The machine bottle production process without the injection point, good bottle products, beautiful appearance 2, The machine adopts multi-speed rotating grinding repression approach to production, to ensure high productivity 3, The machine rotary manner aero-assisted quit threaded mode, to avoid stripping the thread damage caused strong 4, The machine is compact, fully automated operation 5, The machine replacement material molds convenient and easier maintenance festival time

We Have The Right Products to Fit Your Needs Purchase

Zhangjiagang Eceng Machinery Co., Ltd., established in 2007, Our factory spans over 10,000 square meters, and we hold independent research and development patents. We offer a comprehensive production system for PET liquid packaging. Our main products include fully automatic and semi auto bottle blowing machines, jar blowing machines, bottle cap compression molding machines, ISBM machines(injection stretch blow molding machines), self-adhesive labeling machines, OPP labeling machines, sleeve labeling machines, baler, Film shrink wrapping machine, carton packing machines, Pelletizing machines, blow moulds, injection pet preform mold, bottle cap molds, air compressors, cold dryer, and chiller. As a leading one-stop service provider in PET liquid packaging, we supply factory direct products to over 170 countries and look forward to building long-term partnerships worldwide

Exhibition and Customer Visit

Packaging & Shipping

FAQ

Q:Your company is a trading company or a direct factory

A:We are a direct factory which locates in Zhangjiagang city. in close proximity to Shanghai and Wuxi. If you arrive at either Shanghai or Wuxi, we can arrange transportation to pick you up and accompany you for a visit to our factory

Q: How can I know your machine works well

A: Before delivery, we will debug the production line, take photos, videos and send them to you via mail or instant tools. And you are welcome to come to visit our factory, and see the machine running

Q:All of your products are made by yourself or compacted via purchasing the others

A:We have independent technical team who focus on making machines, all the products are made by our technical team

Eceng presents a reliable 24 cavity plastic bottle cap making machine designed for professionals working from home who need high output, consistent quality, and easy operation. This plastic bottle cap compression moulding machine reaches a high speed of 28,000 pieces per hour, making it a strong choice for small-scale production, rapid prototyping, or growing home-based manufacturing operations. It combines practical design with robust performance, allowing users to produce large quantities of caps without compromising on precision or finish.

The machine’s 24-cavity system boosts productivity by molding many caps at once. Each cavity is precisely machined to ensure uniform caps with smooth edges and consistent dimensions. This uniformity reduces waste and downstream inspection time, which is important for professionals who must manage multiple tasks while working from home. The high-speed capability means you can meet tight deadlines and sudden order increases with confidence.

Eceng’s compression moulding approach provides several advantages. It minimizes material waste by using exact material amounts for each cap, and the process produces less flashing compared to other methods. Caps come out with a clean appearance, ready for minimal finishing. The machine supports common thermoplastics used for bottle caps, such as HDPE and PP, offering flexibility for different product needs.

User-friendly controls simplify setup and operation. The machine features an intuitive control panel that allows operators to set cycle times, temperature, and pressure with ease. Clear indicators and adjustable parameters mean even those new to compression moulding can achieve reliable results after a short learning curve. For professionals working from home, this ease of use is essential—less time spent troubleshooting and more time producing.

Durability and build quality are key. Eceng has engineered this machine with sturdy components and a compact footprint suitable for limited workshop spaces. The machine’s frame and mechanical parts are made to withstand continuous operation, ensuring long service life. Regular maintenance is straightforward, with accessible parts and clear service points that help maintain peak performance with minimal downtime.

Safety is built into the design. The machine includes protective guards and emergency stop features to protect operators during operation. For home-based professionals who may work solo, these safety measures provide peace of mind and help maintain a safe working environment. Safety interlocks prevent access to moving parts during a cycle, and thermal protections guard against overheating.

Energy efficiency is another consideration. The Eceng machine is optimized to use power effectively during high-speed runs, reducing overall energy consumption compared to older, less efficient models. For professionals working from home, controlling utility costs is important, and this machine’s design helps keep operational expenses in check.

Flexibility in tooling supports different cap sizes and styles. The 24 cavity mold can be swapped or customized to match specific product designs. Eceng offers tooling support and can help customize molds for threaded closures, snap-fit caps, or specialty shapes. This adaptability allows home-based producers to diversify their product lines without investing in multiple machines.

Consistent cycle timing and precise temperature control contribute to high-quality output. Each production run yields caps with consistent wall thickness and sealing surfaces, essential for bottle closures that must fit reliably. The compression moulding process also tends to produce parts with better surface finish, reducing the need for post-processing.

Eceng provides technical support and documentation, helping users set up the machine in a home workshop environment. Training materials and troubleshooting guides are included to reduce setup time. Spare parts and maintenance kits are available, ensuring that professionals can keep production going with minimal interruption.

The machine’s compact design fits well in small production spaces while still delivering industrial-level throughput. It offers a practical balance of speed, capacity, and footprint. For professionals working from home who need to maximize limited space, this machine is a solid investment that scales with growing demand.

The Eceng 24 cavity plastic bottle cap making machine is a high-speed, reliable, and user-friendly compression moulding solution tailored to professionals working from home. It delivers 28,000 pieces per hour, consistent quality, energy-efficient operation, and flexible tooling options. Built for durability and ease of maintenance, it includes safety features and clear controls to support solo operators. Whether you are growing a home-based business, producing custom runs, or expanding capacity, this machine helps you achieve professional results with strong throughput and dependable performance.
