K4 300ml Water Bottle Moulding Machine

One
MOQ
K4 300ml Water Bottle Moulding Machine
Features Gallery Product Description Request A Quote
Features
Specifications
Model Number: K4
Color: White
Output: 6000bph
Weight: 4.3ton
Highlight:

300ml water bottle moulding machine

,

6000BPH water bottle moulding machine

,

4 cavity pet blowing machine 6000BPH

Basic Infomation
Place of Origin: CHINA
Brand Name: ECENG
Certification: CE SGS ISO
Model Number: K4
Payment & Shipping Terms
Packaging Details: film/wooden
Delivery Time: 45days
Payment Terms: TT LC western Union
Supply Ability: 10sets Per month
Product Description

K4 4cavity 6000BPH Fully electric pet bottle blowing machine PET 300ml water bottleK4 300ml Water Bottle Moulding Machine 0



K4 300ml Water Bottle Moulding Machine 1

K4 300ml Water Bottle Moulding Machine 2

model k4
Bottle type specification Cavity 4
Theory output 8000-10000
Max.volume 200ml-2000ml
Bottle mouth maximum overall diameter 25-29mm
Bottle biggest diameter 100mm
Bottle maximum height 330mm
Power specifications Light tube quantity 16pcs
Maximum heating power 20KW
All electric machine installation 29KW
Actual consumption 30%-60%
Air pressure specification Work pressure 5-6kg/cm2
Low-pressure gas consumption 6000L/min
Blow bottle pressure 25-45kg/cm2
Higher -pressure gas consumption 6000Ltr/min
Forzen water specification Work pressure 5-6 kg/cm2
Temperature range 10°C
Consumption 8000kcal/hr
Forzen water flow 120L/min
Machine specification Size of the machine 3.6x1.6x1.9
Weight of the machine 4.3ton





Eceng K4 High Speed 500ml 1L 2L plastic pet drum Blow Molding Machines Oil Bottle Blowing making Machine(max volume: 2L)

K series is a stable two-step blow-down stretch automatic blowing machine.It can be used from 4 cavity to 12 cavity with a speed of 1500 bottles per hour (750 ml plastic bottles),plastic bottle,suitable for blowing any kind of carbonated beverage bottle,sparkling beverage bottle,pure water bottle, mineral water bottle,fruit juice beverage bottle,cosmetic bottles,large diameter bottles, high temperature resistance bottles and other packaging bottles.



Kseries linear bottle blowing machine features:
1.stable and accurate running at high speed,adopt more stable and advanced microcomputer PLC control system.
2. production process is fully automated, with the advantages of low investment, high efficiency, easy operation, simple maintenance and safety.
3. suitable for flexible production of quantity and various bottle shape,wide range of applications,meet customer needs.
4. manual and automatic methods of operation, human-machine interface control, simple operation.
5. servo transmission system, high positioning accuracy, fast speed stability and good reliability.
6. less than 0.2% scrap rate for finished bottle .
