10000bph Plastic Pet Bottle Stretch Blow Moulding Machine Full Automatic

10000bph Plastic Pet Bottle Stretch Blow Moulding Machine Full Automatic

  • 10000bph Plastic Pet Bottle Stretch Blow Moulding Machine Full Automatic
  • 10000bph Plastic Pet Bottle Stretch Blow Moulding Machine Full Automatic
  • 10000bph Plastic Pet Bottle Stretch Blow Moulding Machine Full Automatic
  • 10000bph Plastic Pet Bottle Stretch Blow Moulding Machine Full Automatic
  • 10000bph Plastic Pet Bottle Stretch Blow Moulding Machine Full Automatic
  • 10000bph Plastic Pet Bottle Stretch Blow Moulding Machine Full Automatic
  • 10000bph Plastic Pet Bottle Stretch Blow Moulding Machine Full Automatic
10000bph Plastic Pet Bottle Stretch Blow Moulding Machine Full Automatic
Product Details:
Place of Origin: Jiangsu, China
Brand Name: Eceng
Model Number: K6
Payment & Shipping Terms:
Minimum Order Quantity: 1 SET
Price: $35,000.00/Sets >=1 Sets
Packaging Details: standard export wooden case or according to your requirements
Delivery Time: 30days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 10sets per month
Contact Now
Detailed Product Description
Plastic Processed: PET Bottle Volume(ml): 2000 Ml
Application: Bottle Blow Moulding Type: Stretch Blow Moulding
Voltage: 380V,50HZ Dimension(L*W*H): 5.5*1.8*1.9m
Color: Black And White Warranty: 1 Year
Output: 10000bph Port: SHANGHAI
High Light:

Plastic Pet Stretch Blow Moulding Machine

,

10000bph Pet Bottle Blow Moulding Machine

,

5.5*1.8*1.9 m Pet Bottle Blow Moulding Machine

500ml plastic water bottle/juice beverage bottle blowing machine
10000bph Plastic Pet Bottle Stretch Blow Moulding Machine Full Automatic 0
10000bph Plastic Pet Bottle Stretch Blow Moulding Machine Full Automatic 2
specification
             Model                                                                             K6






Bottle type specification
Cavity
6

Max.volume
200ml-2000ml

Bottle mouth maximum overall diameter
25-29mm

Bottle biggest diameter
100mm

Bottle maximum height
330mm


Capacity specification
Theory output
10000BPH

Bottle type volume
600ML

Bottle type weight
13.5g

Bottle type
Round



Power specification
Light tube quantity
32pcs

Light tube power
1.25KW

Maximum heating power
40KW

All electric machine installation
49KW

Actual consumption
30%--60%


Air pressure specification
Work pressure
5-6kg/cm2

Blow bottle pressure
25-45kg/cm2

Higher -pressure gas consumption
8000Ltr/min


Air pressure specification
Work pressure
5-6 kg/cm2

Temperature range
10℃

Consumption
8000kcal/hr

Forzen water flow
120L/min

Machine specification
Machine size
5.5x1.8x1.9

Machine weight
6.1ton
Product Description
K series is a stable two-step blow-down stretch automatic blowing machine.It can be used from 4 cavity to 12 cavity with a speed of 1500 bottles per hour (750 ml plastic bottles),max volume 2L plastic bottle,suitable for blowing any kind of carbonated beverage bottle,sparkling beverage bottle,pure water bottle, mineral water bottle,fruit juice beverage bottle,cosmetic bottles,large diameter bottles, high temperature resistance bottles and other packaging bottles.
K linear bottle blowing machine adopts advanced microcomputer PLC control system, stable performance,manual type and fully automatic type. J series linear bottle blowing machine features: 1.stable and accurate running at high speed,adopt more stable and advanced microcomputer PLC control system. 2. production process is fully automated, with the advantages of low investment, high efficiency, easy operation, simple maintenance and safety. 3. suitable for flexible production of quantity and various bottle shape,wide range of applications,meet customer needs. 4. manual and automatic methods of operation, human-machine interface control, simple operation. 5. servo transmission system, high positioning accuracy, fast speed stability and good reliability. 6. less than 0.2% scrap rate for finished bottle .
Company Introduction
10000bph Plastic Pet Bottle Stretch Blow Moulding Machine Full Automatic 6
Packing&Shipping
10000bph Plastic Pet Bottle Stretch Blow Moulding Machine Full Automatic 8
After Sales Service
1. Installation, debug We will arrange seasoned technician for debug and test production at the same time make the equipment reach the rated producing capacity of the line. 2. Training Our company offer technology training to customer. The content of training is structure and maintenance of equipment, control and operation of equipment. After training, the technician of buyer could master the operation and maintenance, could adjust the process and treat different failures. 3. Quality guarantee We promise that our goods quality, specification and function all meet the demand of contract. One year warranty,during warranty period,All parts and components except those damaged by non-human factors are guaranteed free of charge (vulnerable parts are not included). In addition, the seller provides free spare parts and accessories for shipment with the machine. During warranty period ,the equipment is damaged due to incorrect operation bythe buyer,we provide maintenance solutions,the buyer will cover the loss and cost.during warranty period we provide technical service,which is usually solved by telephone,etc.if not,provide door-to-door service

FAQ
Q:Your company is a trading company or a direct factory?
A:We are a direct factory which locates in Zhangjiagang city.
Q:All of your products are made by yourself or compacted via purchasing the others?
A:We have independent technical team who focus on making machines,all the products are made by our technical team.
Q:What is the ability of your factory?
A:About 80 lines per year.
Q:Do you have any other services about your products?
A:We have a lot of experience on making projects and specifications for our clients,also we have a fixed service system.
Q:How do you make the quotation for clients?
A:The price depends on quality and performance but the clients should be satisfied first.
