Place of Origin: | Jiangsu, China |
Brand Name: | Eceng |
Certification: | CE ISO |
Model Number: | K4 |
Minimum Order Quantity: | 1set |
---|---|
Packaging Details: | standard export wooden case or according to your requirements |
Delivery Time: | 60days |
Payment Terms: | L/C, T/T, Western Union |
Supply Ability: | 500 Set/Sets per Year |
Plastic Processed: | PET | Max.Bottle Height(mm): | 330 Mm |
---|---|---|---|
Neck Diameter(mm): | 29 Mm | Max.Bottle Diameter(mm): | 100 Mm |
Bottle Volume(ml): | 2000 Ml | Condition: | New |
Application: | Bottle | Blow Moulding Type: | Stretch Blow Moulding |
Year: | 2019 | Voltage: | 380V,50HZ |
Dimension(L*W*H): | 3.3*1.6*1.9m | Hollow Part Volume: | 2L |
High Pressure Valve Brand: | SMC | Rotary Cylinder Brand: | SMC |
PLC Brand: | DELTA | Power (kW): | 29 |
Weight (KG): | 3400 KG | Automation: | Automatic |
Warranty: | 1 Year | Key Selling Points: | Automatic |
Applicable Industries: | Manufacturing Plant | Marketing Type: | Hot Product 2019 |
Machinery Test Report: | Provided | Video Outgoing-inspection: | Provided |
Warranty Of Core Components: | 1 Year | Color: | Black And White |
Output: | 7000 | Size Of The Machine: | 3.3*1.6*1.9 |
Weight: | 3.4tons | Power(W): | 29KW |
Port: | Shanghai | ||
Highlight: | Eceng K4 plastic container manufacturing machine,plastic container manufacturing machine 380V 50HZ,pet blowing machine 380V 50HZ |
Model K4
|
|
|
||
Bottle type specification
|
Cavity
|
4
|
||
|
Max.volume
|
2L
|
||
|
Bottle mouth maximum overall diameter
|
25-29mm
|
||
|
Bottle biggest diameter
|
100mm
|
||
|
Bottle maximum height
|
330mm
|
||
Capacity specification
|
Theory output
|
6000BPH
|
||
|
Bottle type volume
|
600ML
|
||
|
Bottle type weight
|
13.5g
|
||
|
Bottle type
|
Round
|
||
Power specification
|
Light tube quantity
|
16pcs
|
||
|
Light tube power
|
1.25KW
|
||
|
Maximum heating power
|
20KW
|
||
|
All electric machine installation
|
29KW
|
||
|
Actual consumption
|
30%--60%
|
||
Air pressure specification
|
Work pressure
|
5-6kg/cm2
|
||
|
Blow bottle pressure
|
25-45kg/cm2
|
||
|
Higher -pressure gas consumption
|
6000Ltr/min
|
||
Air pressure specification
|
Work pressure
|
5-6 kg/cm2
|
||
|
Temperature range
|
10℃
|
||
|
Consumption
|
6000kcal/hr
|
||
|
Forzen water flow
|
120L/min
|
||
Machine specification
|
Machine size
|
3.6x1.6x1.9
|
||
|
Machine weight
|
4.3ton
|
