ISO 2L Automatic PET Stretch Blowing Machine 220V 415V 50HZ

ISO 2L Automatic PET Stretch Blowing Machine 220V 415V 50HZ

  • High Light

    ISO 2L PET Stretch Blowing Machine

    ,

    automatic pet bottle blowing machine 415V 50HZ

    ,

    ISO 2L automatic pet bottle blowing machine

  • Plastic Processed
    PET
  • Max.Bottle Height(mm)
    330 Mm
  • Neck Diameter(mm)
    38 Mm
  • Max.Bottle Diameter(mm)
    100 Mm
  • Bottle Volume(ml)
    2000 Ml
  • Condition
    New
  • Application
    Bottle, Plastic PET Bottle
  • Blow Moulding Type
    Stretch Blow Moulding
  • Voltage
    380V/50HZ, 3phase 380V/220V/415V 50HZ
  • Dimension(L*W*H)
    4.5*2.0*2.3(m)
  • Hollow Part Volume
    2l
  • High Pressure Valve Brand
    Mac
  • Rotary Cylinder Brand
    Smc
  • PLC Brand
    XINJE
  • Power (kW)
    50
  • Weight (KG)
    4500 KG
  • Automation
    Automatic
  • Warranty
    1 Year
  • Key Selling Points
    Automatic
  • Applicable Industries
    Food & Beverage Factory
  • Marketing Type
    Hot Product 2019
  • Machinery Test Report
    Provided
  • Video Outgoing-inspection
    Provided
  • Warranty Of Core Components
    1 Year
  • Automatic
    Yes
  • Color
    Orange
  • PLC
    Mitsubishi
  • High Pressure Valve
    Mac/parker
  • Location
    Zhangjiagang City
  • Air Switch,relay,breaker
    Scheneider
  • Port
    Shanghai
  • Place of Origin
    Jiangsu, China
  • Brand Name
    Eceng
  • Certification
    CE ISO
  • Model Number
    q6000
  • Minimum Order Quantity
    1set
  • Price
    $32,800.00/Sets 1-1 Sets
  • Packaging Details
    package suits transportation for 6000bph Automatic blow PET bottle machine/preform blower
  • Delivery Time
    45days
  • Payment Terms
    L/C, T/T, Western Union
  • Supply Ability
    10 Set/Sets per Month

ISO 2L Automatic PET Stretch Blowing Machine 220V 415V 50HZ

Hot sale Full Automatic PET Blowing Molding Machine sopladora de botellas pet
ISO 2L Automatic PET Stretch Blowing Machine 220V 415V 50HZ 0
specification
Item

Q6000




Bottle type specification
Cavity
4

Theory output
5000~6000

Max.volume
2L

Bottle mouth maximum overall diameter
28-38mm

Bottle biggest diameter
105mm

Bottle maximum height
330mm



Power specification
Light tube quantity
32pcs

Light tube power
1.5KW

Maximum heating power
48KW

All electric machine installation
52KW

Actual consumption
40%--70%



Air pressure specification
Work pressure
7-9kg/cm2

Low-pressure gas consumption
1000L/min

Blow bottle pressure
25-35kg/cm2

Higher -pressure gas consumption
3000Ltr/min


Air pressure specification
Work pressure
5-6 kg/cm2

Temperature range
10℃

Consumption
8000kcal/hr

Frozen water flow
138L/min

Machine specification
Machine size
4.1x1.6x1.9

Machine weight
3.9ton
ISO 2L Automatic PET Stretch Blowing Machine 220V 415V 50HZ 2
Q series is a stable two-step blow-down stretch automatic blowing machine.It can be used from 2 cavity to 9 cavity with a speed of 1000 bottles per hour (500 ml plastic bottles),max volume 2L plastic bottle,suitable for blowing any kind of carbonated beverage bottle,sparkling beverage bottle,pure water bottle, mineral water bottle,fruit juice beverage bottle,cosmetic bottles,large diameter bottles, high temperature resistance bottles and other packaging bottles.
ISO 2L Automatic PET Stretch Blowing Machine 220V 415V 50HZ 4
Our Advantage
1. Resonable price 2. Good after service 3. experienced skilled workers and professional engineers 4. Good quality ,excellent service ,long life mould 5. on time delivery time 6.Our engineers can be online for 24 hours to serve you
Detailed Images
ISO 2L Automatic PET Stretch Blowing Machine 220V 415V 50HZ 6
ISO 2L Automatic PET Stretch Blowing Machine 220V 415V 50HZ 8
ISO 2L Automatic PET Stretch Blowing Machine 220V 415V 50HZ 10
Q linear bottle blowing machine adopts advanced microcomputer PLC control system, stable performance,manual type and fully automatic type. Q series linear bottle blowing machine features: 1.stable and accurate running at high speed,adopt more stable and advanced microcomputer PLC control system. 2. production process is fully automated, with the advantages of low investment, high efficiency, easy operation, simple maintenance and safety. 3. suitable for flexible production of quantity and various bottle shape,wide range of applications,meet customer needs. 4. manual and automatic methods of operation, human-machine interface control, simple operation. 5. servo transmission system, high positioning accuracy, fast speed stability and good reliability. 6. less than 0.2% scrap rate for finished bottle .
Company Introduction
ISO 2L Automatic PET Stretch Blowing Machine 220V 415V 50HZ 12
Packing&Shipping
ISO 2L Automatic PET Stretch Blowing Machine 220V 415V 50HZ 14
After Sales Service
1. Installation, debug We will arrange seasoned technician for debug and test production at the same time make the equipment reach the rated producing capacity of the line. 2. Training Our company offer technology training to customer. The content of training is structure and maintenance of equipment, control and operation of equipment. After training, the technician of buyer could master the operation and maintenance, could adjust the process and treat different failures. 3.the sample service 1'We can send you the video of the running machine. 2'You are welcome to come to visit our factory,and see the machine running. 4.We can design the machines according your requirements,at the same time we will give you our professional suggestion,as you know,we have been in this industry for 12 years. 5.We provide one year warranty 6.well-trained & experienced staff are to answer all your inquiries in English and Chinese 7 .12 Months guarantee and life-long technical support. 8.Your business relationship with us will be confidential to any third party. 9. Good after-sale service offered, please get back to us if you got any questions.
ISO 2L Automatic PET Stretch Blowing Machine 220V 415V 50HZ 16
ISO 2L Automatic PET Stretch Blowing Machine 220V 415V 50HZ 18
ISO 2L Automatic PET Stretch Blowing Machine 220V 415V 50HZ 20
FAQ
Q:Your company is a trading company or a direct factory?
A:We are a direct factory which locates in Zhangjiagang city.
Q:All of your products are made by yourself or compacted via purchasing the others?
A:We have independent technical team who focus on making machines,all the products are made by our technical team.
Q:What is the ability of your factory?
A:About 80 lines per year.
Q:Do you have any other services about your products?
A:We have a lot of experience on making projects and specifications for our clients,also we have a fixed service system.
Q:How do you make the quotation for clients?
A:The price depends on quality and performance but the clients should be satisfied first.
