Full Automatic Pet Bottle Molding Making Machine 50KW 28 Mm

Full Automatic Pet Bottle Molding Making Machine 50KW 28 Mm

Full Automatic Pet Bottle Molding Making Machine 50KW 28 Mm
Full Automatic Pet Bottle Molding Making Machine 50KW 28 Mm
Full Automatic Pet Bottle Molding Making Machine 50KW 28 Mm
Product Details:
Place of Origin: Jiangsu, China
Brand Name: Eceng
Certification: CE ISO
Model Number: YCQ-2L-2
Payment & Shipping Terms:
Minimum Order Quantity: 1set
Price: $10,000.00 - $16,000.00/Sets
Packaging Details: standard export wooden case or according to your requirements of hot sell 2l pet blowing machine for industrial quality
Delivery Time: 45days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 20 Set/Sets per Month
Contact Now
Detailed Product Description
Plastic Processed: PET Max.Bottle Height(mm): 330 Mm
Neck Diameter(mm): 28 Mm Application: Bottle
Key Selling Points: Easy To Operate Warranty Of Core Components: 1 Year
Power(W): 50KW
High Light:

Full Automatic Pet Bottle molding Machine

,

50KW Pet Bottle Making Machine

,

28 mm Pet Bottle molding Machine

Machine Features:

1. High safety: No body injury hidden danger, machine avoids the danger of manual bottle taking, reduce the lost caused by accident, and increase productivity.



2.High speed and efficiency: adopts to high speed precision servo motor to control the pathway running.



3.Stable performance: adopts to SIEMENS man machine touch screen computer control system, which has the advantage of accurate, fast and stable. The structure is simple, heater and machine main part connected with slide way one body type, which is simple and easy to maintain.



4.Testing components use famous electrical equipment from Germany and Japan. Strong current control use

international famous brand, the performance stable and accurate.



5. Adopts to infrared tubes to heat the preforms. The tubes controlled in closed loop, which can well avoid the influence caused by outer voltage to the preform heating. The distance between tubes and performs can be easily adjusted, this is good for different bottle shapes and quality requirements.



6. pet bottle blow moulding equipment has the function of automatic alarm and fault detect.



7. pet bottle blow moulding equipment
can keep 9 different data of 9 different blowing drafts. When change molds and performs, can straight use

the data without redressing the data, very easy to operate.



8. Adpot to imported pneumatic components from Germany Japan Taiwan etc, can ensure running fast with zero fault rate.



9. pet bottle blow moulding equipment
is high reaction, exchange fast, low fault rate, and running stable. The whole machine adopts to super

standard shockproof structure, which can reduce the shock to the lowest when machine in high speed running. This prolong the use life of the components.



10. Air circuit has two parts, action and blowing, it can fulfill different air pressure requirements of blowing and action. Can also buy high pressure blowing exhaust air recycle system, which will save air by 10-15%



11. Adopts to the new type double bend arm and four pull rod hydraulic clamping structure. High clamping force, and it will enlarge the pressure when blowing.

Full Automatic Pet Bottle Molding Making Machine 50KW 28 Mm 0

hot sell 2l pet blowing machine for industrial quality



Full Automatic Pet Bottle Molding Making Machine 50KW 28 Mm 2



Full Automatic Pet Bottle Molding Making Machine 50KW 28 Mm 3

Full Automatic Pet Bottle Molding Making Machine 50KW 28 Mm 5

YCQ series is a stable two-step blow-down stretch automatic blowing machine.It can be used from 2 cavity to 6 cavity with a speed of 1000 bottles per hour (500 ml plastic bottles),max volume 2L plastic bottle,suitable for blowing any kind of carbonated beverage bottle,sparkling beverage bottle,pure water bottle, mineral water bottle,fruit juice beverage bottle,cosmetic bottles,large diameter bottles, high temperature resistance bottles and other packaging bottles.

Feature:

A. Advanced PLC control system, stable and excellent performance.

B. Conveyor belt automatically feeds preforms.

C.Strong penetrability and good and swift distribution of the heat by letting the bottles rotate by itself and revolute in the rails simultaneously inthe  infrared pre-heater.

D. High adaptability,preform absorbs heat by adjusting the distance between lamp and reflector.With automatic constant temperature device,temperature is kept within a certain range.

E. Safety locks are provided during each mechanical action to protect operator's safety.

F. Use cylinder instead of hydraulic cylinder, low pollution, low noise.

G. Use different air pressure for blowing and machine operation,energy saving and environmental protection.

H. Equipped with high pressure and double-crank linkage clamping, providing high clamping force.

I. Two ways of operating: automatic and manual.

J. Safe, reliable, unique valve position design makes blowing process easier to control.

K. Low-cost, high-efficiency, easy-to-operate, easy-to-maintain, advanced automatic process flow.

L. Avoid bottle contamination.

M. Protection of low temperature cooling system.

N. Easy to install and start.

O. Low scrap rate.

Full Automatic Pet Bottle Molding Making Machine 50KW 28 Mm 7



Item

YCQ-2L-2

Bottle type specification

Cavity

2

Theory output

2000-2500

Max.volume

2L

Bottle mouth maximum overall diameter

80mm

Bottle biggest diameter

100mm

Bottle maximum height

330mm

Power specifications

Light tube quantity

32pcs

Maximum heating power

24KW

All electric machine installation

27KW

Actual consumption

8.1KW

Air pressure specification

Work pressure

7-9kg/cm2

Low-pressure gas consumption

1000L/min

Blow bottle pressure

25-35kg/cm2

Higher -pressure gas consumption

1500Ltr/min

Forzen water specification

Work pressure

5-6 kg/cm2

Temperature range

10°C

Consumption

5000kcal/hr

Forzen water flow

30L/min

Machine specification

Size of the machine

2.25x1.6x1.7

Weight of the machine

2.5ton

Full Automatic Pet Bottle Molding Making Machine 50KW 28 Mm 9



Fully automatic,low investment,high efficiency,easy operation, simple maintenance and safety.

 Full Automatic Pet Bottle Molding Making Machine 50KW 28 Mm 11

Servo transmission system,high positioning accuracy, fast speed and stability, good reliability.Gas circuit design will divide action and blowing into three parts to meet the needs of different pressure for blowing bottles and movement;Adopt high pressure and double crank arm link locking,strong clamping force.

 Full Automatic Pet Bottle Molding Making Machine 50KW 28 Mm 13

Auto-loader improves working efficiency,accurate transportation,reliable and durable,raw materials are completely free of moisture,pollution,foreign matter, and loss during feeding process.Realize transportation process of feeding process, avoid danger of high-altitude feeding, reduce labor intensity and increase production efficiency.

Full Automatic Pet Bottle Molding Making Machine 50KW 28 Mm 15



Adopt infrared lamp heating, strong penetration, preform rotation heating, track revolution, heating evenly, fast and reliable; heating lamp,reflector width and height can be adjusted to suit preform heating of different structure,with automatic temperature-removal device to ensure the constant temperature of oven.

 Full Automatic Pet Bottle Molding Making Machine 50KW 28 Mm 17

YCQ linear bottle blowing machine adopts advanced microcomputer PLC control system, stable performance,manual type and fully automatic type.








Full Automatic Pet Bottle Molding Making Machine 50KW 28 Mm 21Full Automatic Pet Bottle Molding Making Machine 50KW 28 Mm 23

Our Services

1.Installation Services

Installation Services are available with all new machine purchases. We will provide the technical know-how for your operation smooth transition and support for installing, debugging, operation of the machine, it will indicate you how to use this machine well.


2.Traning Services
We can train your staff to use our machine properly.It means that we offer Customers Training, teaching how to use the systems most efficiently and safely as well as how to maintain optimal operational productivity.


3.After Sales Service
We offer the Preventative Maintenance and After Sales Service. For we strongly feels about the importance of supporting our customers and the product solutions we provide.Consequently we offer comprehensive maintenance options to prevent equipment issues before they become problems. Also we offer one year guarantee period and lifelong technical support!
