Full Automatic 4 Cavity PET Bottle Blowing Machine Plastic Stretch Water Juice CSD Beverage

Full Automatic 4 Cavity PET Bottle Blowing Machine Plastic Stretch Water Juice CSD Beverage

  • High Light

    4 Cavity PET Stretch Blowing Machine

    ,

    2000ml Bottle Stretch Blowing Machine

    ,

    CSD Beverage PET Bottle Blowing Machine

  • Plastic Processed
    PET
  • Max.Bottle Height(mm)
    330 Mm
  • Neck Diameter(mm)
    28 Mm
  • Max.Bottle Diameter(mm)
    105 Mm
  • Bottle Volume(ml)
    2000 Ml
  • Condition
    New
  • Application
    Bottle
  • Blow Moulding Type
    Stretch Blow Moulding
  • Voltage
    380V,50HZ
  • Dimension(L*W*H)
    4.1*1.6*1.9m
  • Power (kW)
    52
  • Weight (KG)
    3900 KG
  • Automation
    Automatic
  • Warranty
    1 Year
  • Machinery Test Report
    Provided
  • Warranty Of Core Components
    1 Year
  • Automatic
    Yes
  • Output
    6000bph
  • Place of Origin
    Jiangsu, China
  • Brand Name
    Eceng
  • Certification
    CE SGS ISO
  • Model Number
    Q6000
  • Minimum Order Quantity
    1set
  • Price
    $26,800.00/Sets 1-1 Sets
  • Packaging Details
    standard export wooden case or according to your requirements
  • Delivery Time
    45days
  • Payment Terms
    L/C, T/T, Western Union
  • Supply Ability
    500 Set/Sets per Year

Full Automatic 4 Cavity PET Bottle Blowing Machine Plastic Stretch Water Juice CSD Beverage

Eceng Automatic 6000bph drink bottle making stretch blow moulding machine price

Features of cooking oil bottle blowing machine :



1. Stable and fine performance with advanced PLC.



2. Conveying perform automatically with conveyor.



3. Strong penetrability and good and swift distribution of the heat by letting the bottles rotate by itself and revolute in the rails simultaneously in the infrared preheater.



4. Well adjustability to enable the preheater to preheat preform in shapes by adjusting the light tube and the length of the reflecting board in the preheating area, and eternal temperature in the preheater with an automatic thermostatic apparatus.



5.High safeties with security automatic-locking apparatus in each mechanical action, which will make the procedures turn into a state of safety in case of a breakdown in certain procedure.



6.No contamination and low noise with the air cylinder to drive the action instead of the oil pump.

7. Satisfaction with different atmospheric pressure for blowing and mechanical action by dividing the blowing and action into three parts in the air pressure diagram of the machine.



8. Strong clamping force with high pressure and double crank links to lock the mold.



9. Low cost, high efficiency, easy operation, good interchangeability, easy maintenance, etc, with automatic technological process.

Full Automatic 4 Cavity PET Bottle Blowing Machine Plastic Stretch Water Juice CSD Beverage 0
specification
Item

Q6000




Bottle type specification
Cavity
4

Theory output
6000

Max.volume
2L

Bottle mouth maximum overall diameter
28-38mm

Bottle biggest diameter
105mm

Bottle maximum height
330mm



Power specification
Light tube quantity
32pcs

Light tube power
1.5KW

Maximum heating power
48KW

All electric machine installation
52KW

Actual consumption
40%-70%


Air pressure specification
Work pressure
7-9kg/cm2

Low-pressure gas consumption
1000L/min

Blow bottle pressure
25-35kg/cm2

Higher -pressure gas consumption
3000Ltr/min


Air pressure specification
Work pressure
5-6 kg/cm2

Temperature range
10℃

Consumption
8000kcal/hr

Frozen water flow
138L/min

Machine specification
Machine size
4.1x1.6x1.9

Machine weight
3.9ton
Full Automatic 4 Cavity PET Bottle Blowing Machine Plastic Stretch Water Juice CSD Beverage 2

Product Description
Full Automatic 4 Cavity PET Bottle Blowing Machine Plastic Stretch Water Juice CSD Beverage 5
Q series is a stable two-step blow-down stretch automatic blowing machine.It can be used from 2 cavity to 9 cavity with a speed of 1000 bottles per hour (500 ml plastic bottles),max volume 2L plastic bottle,suitable for blowing any kind of carbonated beverage bottle,sparkling beverage bottle,pure water bottle, mineral water bottle,fruit juice beverage bottle,cosmetic bottles,large diameter bottles, high temperature resistance bottles and other packaging bottles.
Detailed Images
Full Automatic 4 Cavity PET Bottle Blowing Machine Plastic Stretch Water Juice CSD Beverage 7


Q linear bottle blowing machine adopts advanced microcomputer PLC control system, stable performance,manual type and fully automatic type. Q series linear bottle blowing machine features: 1.stable and accurate running at high speed,adopt more stable and advanced microcomputer PLC control system. 2. production process is fully automated, with the advantages of low investment, high efficiency, easy operation, simple maintenance and safety. 3. suitable for flexible production of quantity and various bottle shape,wide range of applications,meet customer needs. 4. manual and automatic methods of operation, human-machine interface control, simple operation. 5. servo transmission system, high positioning accuracy, fast speed stability and good reliability. 6. less than 0.2% scrap rate for finished bottle .
Full Automatic 4 Cavity PET Bottle Blowing Machine Plastic Stretch Water Juice CSD Beverage 11
our advantage
1. Resonable price
2. Good after service
3. experienced skilled workers and professional engineers
4. Good quality ,excellent service ,long life mould
5. on time delivery time
6.our engineers can be online for 24 hours to serve you
Company Introduction
Full Automatic 4 Cavity PET Bottle Blowing Machine Plastic Stretch Water Juice CSD Beverage 13
Packing&Shipping
Full Automatic 4 Cavity PET Bottle Blowing Machine Plastic Stretch Water Juice CSD Beverage 15

After sales service

* Instruction for Installation and Debugging
Before delivery, SMART takes responsible for debugging of cooking oil bottle blowing machine ,
in order to make sure the provided machine could be safely and smoothly put into operation.

SMART also take responsibility to have debugging overseas, and Client abroad please sends invitation forward of time to engineer of SMART, provides the engineer with round-trip tickets, accommodation, vehicle and salary.

* User Training
Technical training will be provided by SMART before delivery so that users would understand the machine features and how to operate the machine by themselves.

* Warranty Period
The warranty period for SMART machine is one year with a lifelong maintenance. If there is special requirement, other stipulated warranty period may be made after mutual agreement.
