Pet Plastic Bottle Blowing Mold Machine High Efficiency Full Automatic With 4 Cavity

Pet Plastic Bottle Blowing Mold Machine High Efficiency Full Automatic With 4 Cavity

Pet Plastic Bottle Blowing Mold Machine High Efficiency Full Automatic With 4 Cavity
Pet Plastic Bottle Blowing Mold Machine High Efficiency Full Automatic With 4 Cavity
Pet Plastic Bottle Blowing Mold Machine High Efficiency Full Automatic With 4 Cavity
Product Details:
Place of Origin: CHINA
Brand Name: ECENG
Certification: CE SGS ISO
Model Number: K4
Payment & Shipping Terms:
Minimum Order Quantity: One
Price: Negotiable
Packaging Details: film/wooden
Delivery Time: 45days
Payment Terms: TT LC western Union
Supply Ability: 10sets Per month
Contact Now
Detailed Product Description
Pet Bottle Blowing Machine: Pet Bottle Blowing Machine Automatic Output: 8000-10000bph
Weight: 4.3ton Key Selling Points: Automatic
Machinery Test Report: Provided Video Outgoing-inspection: Provided
High Light:

Pet Plastic Bottle Blowing Mold Machine

,

4 Cavity Pet Blowing Mold Machine

,

Pet Blowing Mold Machine 10000bph

Best Offer! pet plastic bottle high efficiency blow mold full automatic blowing machine with 4 Cavity .



Eceng machine K4:

model k4
Bottle type specification Cavity 4
Theory output 8000-10000
Max.volume 200ml-2000ml
Bottle mouth maximum overall diameter 25-29mm
Bottle biggest diameter 100mm
Bottle maximum height 330mm
Power specifications Light tube quantity 16pcs
Maximum heating power 20KW
All electric machine installation 29KW
Actual consumption 30%-60%
Air pressure specification Work pressure 5-6kg/cm2
Low-pressure gas consumption 6000L/min
Blow bottle pressure 25-45kg/cm2
Higher -pressure gas consumption 6000Ltr/min
Forzen water specification Work pressure 5-6 kg/cm2
Temperature range 10°C
Consumption 8000kcal/hr
Forzen water flow 120L/min
Machine specification Size of the machine 3.6x1.6x1.9
Weight of the machine 4.3ton



Pet Plastic Bottle Blowing Mold Machine High Efficiency Full Automatic With 4 Cavity 0



Pet Plastic Bottle Blowing Mold Machine High Efficiency Full Automatic With 4 Cavity 1

Pet Plastic Bottle Blowing Mold Machine High Efficiency Full Automatic With 4 Cavity 2


Product Description:

K series blowing machine are equipped with automatic perform loading and unloading system. The machine is applicable for all shapes of drinking water bottles, carbonated bottles and hot filling bottles. K4 is composed of three modules: prefrom elevator, perform unscrambler and host machine.
II. Technical Features of PET bottle blowing machine :
1). High Speed: 8000BPH-10000BPH (4-cavity).
2). Less Space consumption: Machine is highly integrated, the construction is highly compact.
3). Less electricity consumption: performs intercept is shorten to the minimum, compared with common.
4).blowing machine 30% electricity can be reduced.
5). High Intelligence: The machine can be controlled through touch screen and running status is shown on it.
6). High Quality: Steady infrared heating system blowing and highly precise blow-mould closing system ensure quality.
7). No Contamination: Closed production zone, good self-lubrication system avoid contamination.
8). High Transparency: Easy maintenance, absolute safely, visual inspection, low noise.

blowing mould
Pet Plastic Bottle Blowing Mold Machine High Efficiency Full Automatic With 4 Cavity 3
Company Introduction
Pet Plastic Bottle Blowing Mold Machine High Efficiency Full Automatic With 4 Cavity 4
Pet Plastic Bottle Blowing Mold Machine High Efficiency Full Automatic With 4 Cavity 5
Pet Plastic Bottle Blowing Mold Machine High Efficiency Full Automatic With 4 Cavity 6
Zhangjiagang Eceng Machinery Co., Ltd is founded in 2007,located in Zhangjiagang city,only 120km away from Shanghai.We are professional manufacturer of PET bottle blowing machines and plastic molds. We manufacture fully-automatic PET bottle blowing machine, injection mold,blowing mold etc.,suitable for 5ml-50L plastic bottles,water bottles,carbonated beverage bottles,oil bottles,cosmetics bottles.We can equip machine from 1-12 cavity,output from hundreds bottles to 20,000 bottles/hour,also provide full set of production system from preform production,bottle blowing,filling to final packaging. Our products has covered all over China and exported to more than 100 countries,including Southest Asia,Middle East,South America,Africa etc.We’d like to provide high quality solution to clients with our enthusiasm and rich experience.We sincerely hope to establish business relationship with friends all over the world.
Packing&Shipping
Pet Plastic Bottle Blowing Mold Machine High Efficiency Full Automatic With 4 Cavity 7
Pet Plastic Bottle Blowing Mold Machine High Efficiency Full Automatic With 4 Cavity 8
Normally the inner package, we will packed by the stretch film. Outer package we will use the export woodencase. Mostly we deliver the goods by sea as the freight is most reasonable in this way.

FAQ
Q:Your company is a trading company or a direct factory?
A:We are a direct factory which locates in Zhangjiagang city.
Q:All of your products are made by yourself or compacted via purchasing the others?
A:We have independent technical team who focus on making machines,all the products are made by our technical team.
Q:What is the ability of your factory?
A:About 80 lines per year.
Q:Do you have any other services about your products?
A:We have a lot of experience on making projects and specifications for our clients,also we have a fixed service system.
Q:How do you make the quotation for clients?
A:The price depends on quality and performance but the clients should be satisfied first.
