Blow your bottle, Shape your dream

|
| Place of Origin: | Jiangsu, China |
| Brand Name: | Eceng |
| Certification: | CE SGS ISO |
| Model Number: | K6 |
| Minimum Order Quantity: | 1set |
|---|---|
| Packaging Details: | standard export wooden case or according to your requirements |
| Delivery Time: | 45days |
| Payment Terms: | L/C, T/T, Western Union |
| Supply Ability: | 8 Set/Sets per Month |
| Plastic Processed: | PET | Max.Bottle Height(mm): | 330 Mm |
|---|---|---|---|
| Neck Diameter(mm): | 28 Mm | Max.Bottle Diameter(mm): | 100 Mm |
| Condition: | New | Blow Moulding Type: | Stretch Blow Moulding |
| Warranty: | 1 Year, One Year For Free | Core Components: | Motor, Pump, Gear, Pressure Vessel, Engine, Gearbox |
| High Light: | High Speed Linear Bottle Machine,12000BPH Linear Bottle Blowing Machine,6 Cavities Linear Bottle Blowing Machine |
||
|
Model K6
|
|
|
||
|
Bottle type specification
|
Cavity
|
6
|
||
|
|
Max.volume
|
200ml-2000ml
|
||
|
|
Bottle mouth maximum overall diameter
|
25-29mm
|
||
|
|
Bottle biggest diameter
|
100mm
|
||
|
|
Bottle maximum height
|
330mm
|
||
|
Capacity specification
|
Theory output
|
10000BPH
|
||
|
|
Bottle type volume
|
600ML
|
||
|
|
Bottle type weight
|
13.5g
|
||
|
|
Bottle type
|
Round
|
||
|
Power specification
|
Light tube quantity
|
32pcs
|
||
|
|
Light tube power
|
1.25KW
|
||
|
|
Maximum heating power
|
40KW
|
||
|
|
All electric machine installation
|
49KW
|
||
|
|
Actual consumption
|
30%--60%
|
||
|
Air pressure specification
|
Work pressure
|
5-6kg/cm2
|
||
|
|
Blow bottle pressure
|
25-45kg/cm2
|
||
|
|
Higher -pressure gas consumption
|
8000Ltr/min
|
||
|
Air pressure specification
|
Work pressure
|
5-6 kg/cm2
|
||
|
|
Temperature range
|
10℃
|
||
|
|
Consumption
|
8000kcal/hr
|
||
|
|
Forzen water flow
|
120L/min
|
||
|
Machine specification
|
Machine size
|
5.5x1.8x1.9
|
||
|
|
Machine weight
|
6.1ton
|
||
K series is a stable two-step blow-down stretch automatic blowing machine.It can be used from 4 cavity to 12 cavity with a speed of 2500 bottles per hour ,max volume 2L plastic bottle,suitable for blowing any kind of carbonated beverage bottle,sparkling beverage bottle,pure water bottle, mineral water bottle,fruit juice beverage bottle,cosmetic bottles,large diameter bottles, high temperature resistance bottles and other packaging bottles.
K6 12000BPH 6 Cavities High-Speed Bottle Making Machine Have the following advantages
1. High Speed: The K6 12000BPH bottle making machine is capable of producing 6 cavities at a high speed, ensuring efficient production for high-volume manufacturers.
2. Accurate: This machine uses advanced technology to ensure that the bottles created are accurate, with consistent dimensions and shapes.
3. Versatile: The K6 12000BPH machine is suitable for a range of bottle sizes (up to 2000ml), making it a versatile option for manufacturers with different production needs.
4. Reliable: Designed with high-quality materials and precision components, this machine is reliable and built to withstand the demands of continuous use.
5. Easy to Use: The K6 12000BPH machine is user-friendly and easy to operate, with a simple and intuitive interface that reduces the need for extensive training.
6. Efficient: With its high-speed production and reliable operation, this bottle making machine is an efficient choice for manufacturers looking to increase their output and streamline their production processes.
