Q6000 Pet Bottle Stretch Blow Molding Making Machine 4 Cavity

Q6000 Pet Bottle Stretch Blow Molding Making Machine 4 Cavity

  • Q6000 Pet Bottle Stretch Blow Molding Making Machine 4 Cavity
  • Q6000 Pet Bottle Stretch Blow Molding Making Machine 4 Cavity
  • Q6000 Pet Bottle Stretch Blow Molding Making Machine 4 Cavity
  • Q6000 Pet Bottle Stretch Blow Molding Making Machine 4 Cavity
  • Q6000 Pet Bottle Stretch Blow Molding Making Machine 4 Cavity
  • Q6000 Pet Bottle Stretch Blow Molding Making Machine 4 Cavity
Q6000 Pet Bottle Stretch Blow Molding Making Machine 4 Cavity
Product Details:
Place of Origin: Jiangsu, China
Brand Name: Eceng
Certification: CE SGS ISO
Model Number: Q6000
Payment & Shipping Terms:
Minimum Order Quantity: 1set
Price: $26,800.00/Sets 1-1 Sets
Packaging Details: standard export wooden case or according to your requirements
Delivery Time: 45days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 500 Set/Sets per Year
Contact Now
Detailed Product Description
Plastic Processed: PET Max.Bottle Height(mm): 330 Mm
Neck Diameter(mm): 28 Mm Max.Bottle Diameter(mm): 105 Mm
Bottle Volume(ml): 2000 Ml Condition: New
Application: Bottle Blow Moulding Type: Stretch Blow Moulding
High Light:

Pet Linear Bottle Blow Molding Machine

,

Q6000 Pet Stretch Blow Molding Machine

,

Pet 4 Cavity Blow Molding Machine

Eceng Q6000 4cavity stretch pet blow moulding machine for mineral water bottle production line.



Model Q6000

Bottle type specification



Cavity 4
Max.volume 2L
Bottle mouth maximum overall diameter 28-38mm
Bottle biggest diameter 105mm
Bottle maximum height 330mm
Production specification Theoretical output 6000BPH
Bottle type capacity 500ML
Bottle type weight 17g
Bottle type circular
Power specification Light tube quantity 32pcs
Light tube power 1.5KW
Maximum heating power 48KW
All electric machine installation 52KW
Actual consumption 40%--70%

Air pressure specification



Work pressure 7-9kg/cm2
Low-pressure gas consumption 1000L/min
Blow bottle pressure 25-35kg/cm2
Higher -pressure gas consumption 3000Ltr/min

Air pressure specification



Work pressure 5-6 kg/cm2
Temperature range 10℃
Consumption 8000kcal/hr
Forzen water flow 138L/min

Machine specification



Machine size 4.2x1.6x1.9
Machine weight 4.5ton

Product Description
1. The Pet Bottle Stretch Blow Molding Machine 4 Cavity Q6000 Bottle Blower 6000BPH is a high-end solution for producing top-quality PET bottles at high speeds. With its advanced technology, this machine can produce up to 6000 bottles per hour, making it ideal for large-scale manufacturing operations.
2. Featuring a 4-cavity design, the Pet Bottle Stretch Blow Molding Machine Q6000 can produce 4 bottles at once, ensuring optimal efficiency and reducing production time. This feature is particularly valuable for large-scale production runs, where fast and reliable performance is a must.
3. The Pet Bottle Stretch Blow Molding Machine 4 Cavity Q6000 Bottle Blower is equipped with advanced functions such as automatic lubrication, preform feeding and bottle ejection systems, ensuring smooth and reliable operation. This feature helps to minimize downtime and ensures consistent quality throughout the production process.
4. With its sleek, modern design and user-friendly interface, the Pet Bottle Stretch Blow Molding Machine 4 Cavity Q6000 is easy to operate and maintain. It is ideal for use in a range of applications, from food and beverage packaging to cosmetics and household products.
5. If you're looking for a high-quality, reliable solution for producing PET bottles in large quantities, the Pet Bottle Stretch Blow Molding Machine 4 Cavity Q6000 Bottle Blower is the ideal choice. Its advanced technology, accurate performance, and efficient operation make it a top-of-the-line option for any manufacturing operation.

Q6000 Pet Bottle Stretch Blow Molding Making Machine 4 Cavity 0
Detailed Images


Q6000 Pet Bottle Stretch Blow Molding Making Machine 4 Cavity 3Q6000 Pet Bottle Stretch Blow Molding Making Machine 4 Cavity 4
Q linear bottle blowing machine adopts advanced microcomputer PLC control system, stable performance,manual type and fully automatic type. Q series linear bottle blowing machine features: 1.stable and accurate running at high speed,adopt more stable and advanced microcomputer PLC control system. 2. production process is fully automated, with the advantages of low investment, high efficiency, easy operation, simple maintenance and safety. 3. suitable for flexible production of quantity and various bottle shape,wide range of applications,meet customer needs. 4. manual and automatic methods of operation, human-machine interface control, simple operation. 5. servo transmission system, high positioning accuracy, fast speed stability and good reliability. 6. less than 0.2% scrap rate for finished bottle .
Q6000 Pet Bottle Stretch Blow Molding Making Machine 4 Cavity 6
our advantage
1. Resonable price
2. Good after service
3. experienced skilled workers and professional engineers
4. Good quality ,excellent service ,long life mould
5. on time delivery time
6.our engineers can be online for 24 hours to serve you
Company Introduction
Q6000 Pet Bottle Stretch Blow Molding Making Machine 4 Cavity 8
Packing&Shipping
Q6000 Pet Bottle Stretch Blow Molding Making Machine 4 Cavity 10
Q6000 Pet Bottle Stretch Blow Molding Making Machine 4 Cavity 12
Q6000 Pet Bottle Stretch Blow Molding Making Machine 4 Cavity 13

Q6000 Pet Bottle Stretch Blow Molding Making Machine 4 Cavity 16
Q6000 Pet Bottle Stretch Blow Molding Making Machine 4 Cavity 18
