K5L4 Pet Oil Bottle Stretch Blowing Machine High Speed 380V 50HZ

K5L4 Pet Oil Bottle Stretch Blowing Machine High Speed 380V 50HZ

K5L4 Pet Oil Bottle Stretch Blowing Machine High Speed 380V 50HZ
K5L4 Pet Oil Bottle Stretch Blowing Machine High Speed 380V 50HZ
K5L4 Pet Oil Bottle Stretch Blowing Machine High Speed 380V 50HZ
Product Details:
Place of Origin: Jiangsu, China
Brand Name: Eceng
Certification: CE ISO
Model Number: K5L4
Payment & Shipping Terms:
Minimum Order Quantity: 1set
Price: $35,800.00/Sets 1-1 Sets
Packaging Details: standard export wooden case or according to your requirements
Delivery Time: 30days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 500 Set/Sets per Year
Contact Now
Detailed Product Description
Bottle Volume(ml): 2000 Ml Condition: New
Application: Bottle Blow Moulding Type: Stretch Blow Moulding
Voltage: 380V,50HZ Dimension(L*W*H): 7.8*1.95*2.54m
Hollow Part Volume: 5L Applicable Industries: Manufacturing Plant
High Light:

K5L4 Oil Bottle Blowing Machine

,

Pet Oil Bottle Stretch Blowing Machine

,

50HZ Oil Bottle Blowing Machine



Eceng K5L4 High Speed Oil Bottle Blowing Making Machine 1L 2L 3L 4L 5L 3000-4000BPH


K5L4 Pet Oil Bottle Stretch Blowing Machine High Speed 380V 50HZ 0
K5L4 Pet Oil Bottle Stretch Blowing Machine High Speed 380V 50HZ 2
specification
             Model                                                                    K5L4






Bottle type specification
Cavity
4

Max.volume
5L

Bottle mouth maximum overall diameter
38-63mm

Bottle biggest diameter
185mm

Bottle maximum height
360mm


Capacity specification
Theory output
3000-4000BPH

Bottle type volume
5000ML

Bottle type weight
220g

Bottle type
Round



Power specification
Light tube quantity
32pcs

Light tube power
2KW

Maximum heating power
64KW

All electric machine installation
75KW

Actual consumption
40%--60%


Air pressure specification
Work pressure
5-6kg/cm2

Blow bottle pressure
25-45kg/cm2

Higher -pressure gas consumption
8000Ltr/min


Air pressure specification
Work pressure
5-6 kg/cm2

Temperature range
10℃

Consumption
18000kcal/hr

Forzen water flow
120L/min

Machine specification
Machine size
7.8x1.95x2.54

Machine weight
10.6ton


The Eceng K5L4 high-speed oil bottle blowing making machine is an excellent solution for manufacturers who need to produce bottles quickly and efficiently. With the ability to produce bottles in sizes ranging from 1L to 5L and at a speed of 3000-4000 bottles per hour, this machine is a great investment for companies that need to increase their production capacity.

One of the main advantages of the Eceng K5L4 machine is that it is designed to be easy to operate. With a user-friendly interface and intuitive controls, it is simple for operators to set up the machine and start producing bottles immediately. Additionally, the machine is designed to be highly reliable, with automatic error detection and correction systems that help to prevent downtime and minimize waste.

Another key feature of the Eceng K5L4 machine is its versatility. It can produce bottles in a wide range of shapes and sizes, making it suitable for use in a variety of different industries. Whether you need to produce bottles for the food and beverage industry, the pharmaceutical industry, or any other industry, this machine is capable of meeting your needs.

Overall, the Eceng K5L4 high-speed oil bottle blowing making machine is an excellent investment for any company that needs to increase its production capacity. With its ease of use, reliability, and versatility, it is a great option for businesses that want to stay competitive in today's fast-paced market.

K5L4 Pet Oil Bottle Stretch Blowing Machine High Speed 380V 50HZ 4
K5L4 Pet Oil Bottle Stretch Blowing Machine High Speed 380V 50HZ 6
Kseries linear bottle blowing machine features:
1.stable and accurate running at high speed,adopt more stable and advanced microcomputer PLC control system.
2. production process is fully automated, with the advantages of low investment, high efficiency, easy operation, simple maintenance and safety.
3. suitable for flexible production of quantity and various bottle shape,wide range of applications,meet customer needs.
4. manual and automatic methods of operation, human-machine interface control, simple operation.
5. servo transmission system, high positioning accuracy, fast speed stability and good reliability.
6. less than 0.2% scrap rate for finished bottle .
blowing mould
K5L4 Pet Oil Bottle Stretch Blowing Machine High Speed 380V 50HZ 8
K5L4 Pet Oil Bottle Stretch Blowing Machine High Speed 380V 50HZ 10
Company Introduction
K5L4 Pet Oil Bottle Stretch Blowing Machine High Speed 380V 50HZ 12
K5L4 Pet Oil Bottle Stretch Blowing Machine High Speed 380V 50HZ 14
K5L4 Pet Oil Bottle Stretch Blowing Machine High Speed 380V 50HZ 16
Packing&Shipping
K5L4 Pet Oil Bottle Stretch Blowing Machine High Speed 380V 50HZ 18
K5L4 Pet Oil Bottle Stretch Blowing Machine High Speed 380V 50HZ 20
Normally the inner package, we will packed by the stretch film. Outer package we will use the export woodencase. Mostly we deliver the goods by sea as the freight is most reasonable in this way.
After Sales Service
1.Installation, debug
We will arrange seasoned technician for debug and test production at the same time make the equipment reach the rated producing capacity of the line.
2. Training
Our company offer technology training to customer. The content of training is structure and maintenance of equipment, control and operation of equipment. After training, the technician of buyer could  master the operation and maintenance, could adjust the process and treat different failures.
3. the sample service
1' We can send you the video of the running machine.
2' You are welcome to come to visit our factory,and see the machine running.
4. We can design the machines according your requirements,at the same time we will give you our professional suggestion,as you know,we have been in this industry for 12 years.
5. well-trained & experienced staff are to answer all your inquiries in English and Chinese
6 .12 Months guarantee and life-long technical support.
7. Your business relationship with us will be confidential to any third party.
8. Good after-sale service offered, please get back to us if you got any questions.
K5L4 Pet Oil Bottle Stretch Blowing Machine High Speed 380V 50HZ 22
K5L4 Pet Oil Bottle Stretch Blowing Machine High Speed 380V 50HZ 24
K5L4 Pet Oil Bottle Stretch Blowing Machine High Speed 380V 50HZ 26
FAQ
Q:Your company is a trading company or a direct factory?
A:We are a direct factory which locates in Zhangjiagang city.
Q:All of your products are made by yourself or compacted via purchasing the others?
A:We have independent technical team who focus on making machines,all the products are made by our technical team.
Q:What is the ability of your factory?
A:About 80 lines per year.
Q:Do you have any other services about your products?
A:We have a lot of experience on making projects and specifications for our clients,also we have a fixed service system.
Q:How do you make the quotation for clients?
A:The price depends on quality and performance but the clients should be satisfied first.
