49kw Preform 4 Cavity PET Blowing Machine 2400-3000 BPH

49kw Preform 4 Cavity PET Blowing Machine 2400-3000 BPH

  • 49kw Preform 4 Cavity PET Blowing Machine 2400-3000 BPH
  • 49kw Preform 4 Cavity PET Blowing Machine 2400-3000 BPH
  • 49kw Preform 4 Cavity PET Blowing Machine 2400-3000 BPH
  • 49kw Preform 4 Cavity PET Blowing Machine 2400-3000 BPH
49kw Preform 4 Cavity PET Blowing Machine 2400-3000 BPH
Product Details:
Place of Origin: China
Brand Name: eceng
Certification: CE ISO SGS
Model Number: j4
Payment & Shipping Terms:
Minimum Order Quantity: 1set
Price: $25,000.00 - $45,000.00/Sets
Packaging Details: standard export wooden case or according to your requirements
Delivery Time: 45days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 10 Set/Sets per Month
Contact Now
Detailed Product Description
Plastic Processed: PET Blow Moulding Type: Stretch Blow Moulding
Voltage: 380V,50HZ Hollow Part Volume: 1l-3l
Warranty: 1 Year Key Selling Points: Automatic
After-sales Service Provided: Online Support, Field Installation, Commissioning And Training, Engineers Available To Service Machinery Overseas Output: 2400-3000
High Light:

49kw 4 cavity pet blowing machine

,

4 cavity pet blowing machine 2400-3000 bpn

,

49kw preform blowing machine

4 cavities hot sale jar preform automatic blow molding machine

49kw Preform 4 Cavity PET Blowing Machine 2400-3000 BPH 0

J series blow moulding machine is a specialized equipment designed for large-diameter PET bottles,with features of high automation,wide versatility,and easy operation.It is especially suitable for the production and processing of large-diameter 50-180mm.J series bottle making machine is precisely positioned and adopts advanced microcomputer PLC control system, which can be more stable.
Features:
1.Strong versatility,suitable for 50-180mm diameter,high automatic degree,suitable for preform loading of jar bottle,automatically unloading the bottle.
2.One worker can control two to three machines,high output,can be equipped with all-electric stretching and mould clamping.
3.High heat penetration and preform rotation by itself,making preform subject to even heat during preheating process.
4.Safe, reliable and unique valve position design makes blowing process easier to control
5.Safety locking device in every mechanical action to protect operator's safety.
6.Advanced automatic process flow with low cost,high efficiency,easy operation and easy maintenance.
7.With both automatic and manual operation method.
8.Use different air pressure for blowing and machine operation, energy saving and environmental protection.
9.Easy to install and start, low scrap rate.

49kw Preform 4 Cavity PET Blowing Machine 2400-3000 BPH 1

Item

J4

Bottle type specification

Cavity

4

Theory output

2400-3000

Max.volume

3L

Bottle mouth maximum overall DIdiameter

150mm

Bottle biggest diameter

180mm

Bottle maximum height

400mm

Power specifications

Light tube quantity

32pcs

Light tube power

1.5KW

Maximum heating power

48KW

All electric machine installation

51KW

Actual consumption

35.7KW

Air pressure specification

Work pressure

7-9kg/cm2

Low-pressure gas consumption

1600L/min

Blow bottle pressure

25-35kg/cm2

Higher -pressure gas consumption

3400Ltr/min

Forzen water specification

Work pressure

5-6 kg/cm2

Temperature range

10℃

Consumption

6000kcal/hr

Forzen water flow

50L/min

Machine specification

Size of the machine

4.5*2.0*2.3m

Weight of the machine

4ton



Edible oil PET bottle blowing machine is a two-step automatic blowing equipment specially developed for blowing 5 liters of edible oil bottles, which can meet customers' demands for large-capacity, high-speed, fully automated production.

Auto-loader improves working efficiency,accurate transportation,reliable and durable,raw materials are completely free of moisture,pollution,foreign matter, and loss during feeding process.Realize transportation process of feeding process, avoid danger of high-altitude feeding, reduce labor intensity and increase production efficiency.

Adopt infrared lamp heating, strong penetration, preform rotation heating, track revolution, heating evenly, fast and reliable; heating lamp,reflector width and height can be adjusted to suit preform heating of different structure,with automatic temperature-removal device to ensure the constant temperature of oven.

J linear bottle blowing machine adopts advanced microcomputer PLC control system, stable performance,manual type and fully automatic type.

49kw Preform 4 Cavity PET Blowing Machine 2400-3000 BPH 2

49kw Preform 4 Cavity PET Blowing Machine 2400-3000 BPH 3

49kw Preform 4 Cavity PET Blowing Machine 2400-3000 BPH 4

49kw Preform 4 Cavity PET Blowing Machine 2400-3000 BPH 5

49kw Preform 4 Cavity PET Blowing Machine 2400-3000 BPH 6



49kw Preform 4 Cavity PET Blowing Machine 2400-3000 BPH 7

49kw Preform 4 Cavity PET Blowing Machine 2400-3000 BPH 8

Zhangjiagang Eceng Machinery Co., Ltd is founded in 2007,We manufacture fully-automatic PET bottle blowing machine, injection mold,blowing mold etc.,suitable for 5ml-50L plastic bottles,water bottles,carbonated beverage bottles,oil bottles,cosmetics bottles.We can equip machine from 1-12 cavity,output from hundreds bottles to 36,000 bottles/hour,also provide full set of production system from preform production,bottle blowing,filling to final packaging.
So far Eceng machinery have provided more than 2050 sets machines for more than 170 countries in the world.Our equipments are highly estimated by the clients, and are well known at home and abroad.We sincerely hope to establish business relationship with friends all over the world.
49kw Preform 4 Cavity PET Blowing Machine 2400-3000 BPH 9
49kw Preform 4 Cavity PET Blowing Machine 2400-3000 BPH 10

our advantage:1. Resonable price;2. Good after service;3. experienced skilled workers and professional engineers;4. Good quality ,excellent service ,long life mould;5. on time delivery time;6.our engineers can be online for 24 hours to serve you.



49kw Preform 4 Cavity PET Blowing Machine 2400-3000 BPH 11

Normally the inner package, we will packed by the stretch film. Outer package we will use the export woodencase. Mostly we deliver the goods by sea as the freight is most reasonable in this way.

49kw Preform 4 Cavity PET Blowing Machine 2400-3000 BPH 12

49kw Preform 4 Cavity PET Blowing Machine 2400-3000 BPH 13

FAQ

Q:Your company is a trading company or a direct factory?

A:We are a direct factory which locates in Zhangjiagang city.

Q:All of your products are made by yourself or compacted via purchasing the others?

A:We have independent technical team who focus on making machines,all the products are made by our technical team.

Q:What is the ability of your factory?

A:About 80 lines per year.

Q:Do you have any other services about your products?

A:We have a lot of experience on making projects and specifications for our clients,also we have a fixed service system.

Q:How do you make the quotation for clients?

A:The price depends on quality and performance but the clients should be satisfied first.
